3. Engineering Specification
No. ITEM Specification Remark
1 ENERGY SYNC(V/H) VIDEO POWER LED COLOR
Normal On/On Active ≤ 40W Green
Sleep Mode Off/On Off ≤ 1W Red
Off Mode - Off ≤ 1W Off
2 Audio output Source Min Typ Max
PC 2.7W 3W 3.9W Min : -10%
AV 2.7W 3W 3.9W Max : +30%
TV 2.7W 3W 3.9W
3 D-SUB 1 : RED 2 : Green 10 : Digital GND
Pin configuration 3 : Blue 4 : ID2 (GND)
5 : S.T (GND) 6 : RED GND
7 : Green GND 8 : Blue GND
9 : N.C 10 : D-GND
11: ID0(GND) 12 :SDA
13: H-Sync 14 : V-Sync
15: SCL Shell : GND
4 MTBF Hours(Min) Lamp Life : 50,000 Hours(MIN)
5 Operating Environment Temp : 10 ~ 35 deg
Humidity : 20 ~ 80 %
6 Storage Environment Temp : -10 ~ 60 deg Non condensing
Humidity : 5 ~ 90 % Non condensing
4. Optical Characteristic
No Item Specification Remark
Min Tpy Max
1 Viewing Angle R/L 89/89
<CR≥10> U/D 89/89
2 Luminance Luminance (cd/m
2
) 320 400 PSM : Dynamic, CSM: Cool
White luminance uniformity 75% 80% White (100 IRE)
3 Contrast Ratio CR 2400 3000 All white/ All black
4 CIE Color Coordinates White Wx 0.298 0.313 0.328 In AV input
(Warm) Wy 0.314 0.329 0.344 PSM : Dynamic
White Wx 0.270 0.285 0.300 White (85 IRE)
(Normal) Wy 0.278 0.293 0.308
White Wx 0.261 0.276 0.291
(Cool) Wy 0.268 0.283 0.298
To Next Page
