1. Application range
This specification is applied to the LCD TV used LC01A chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 ºC ± 5 ºC(77 ºF ± 9 ºF), CST: 40 ºC ± 5 ºC
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage: Standard input voltage (AC 100-240 V~ 50 / 60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with
BOM.
5) The receiver must be operated for about 5 minutes prior to the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC :CE, IEC
4. Module General Specification
- 4 -
LGE Internal Use OnlyCopyright © 2010 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
Specification ItemNO. Remark
1 Display Screen Device 42” wide Color Display Module Edgel LCD
16:9
3 LCD Module 22”TFT LCD FHD AUO/LGD: 42LE4500-CA
Humidity : 10 ~ 90 %
5 Input Voltage AC 100-240 V~, 50 / 60Hz
6
2 Aspect Ratio
4 Storage Environment
Temp. : -20 deg ~ 60 deg
22LGD(FHD)
