EXPLODED VIEW PARTS LIST
No. PART NO. DESCRIPTION
120 EAB32761501 Speaker,Full Range L07030A-027 ND35 3W 16OHM 85DB 300HZ 30 X 70 X 22 SOLDER
200 EAJ33945801 LCD,Module-TFT LM220WE1-TLA1 300CD 72% 16/10 800:1 160/160 5ms 4LAMPS LPL
300 ABJ32771501 Cabinet Assembly 22LS4R 22LS4R CABINET ASS’Y 22LS4R CABINET ASS’Y(22”)
ABJ32771503 Cabinet Assembly 22LS4R 22LS4R CABINET ASS’Y 22LS4R CABINET ASS’Y(22”) PAL(CKD)
400 ACQ32411812 Cover Assembly,Rear 22LS4R BACK_COVER ASS’Y (22”_PAL Multi) LPL panel
ACQ32411817 Cover Assembly,Rear 22LS4R-TA BACK_COVER ASS’Y ETC PAL multi LPL, C/SKD
430 AAN32870901 Base Assembly STAND 22ls4r - 22LS4R COVER STAND BASE ASSY
AAN32870903 Base Assembly STAND 22ls4r - 22LS4R COVER STAND BASE ASSY CKD
431 MCK36500501 Cover,Rear MOLD ABS 380 19LS4R ABS, HF-380 19LS4R STAND BODY COVER
MCK36500502 Cover,Rear MOLD ABS 380 19LS4R ABS, HF-380 19LS4R STAND BODY COVER C/SKD
432 AAN31022505 Base Assembly STAND m228w/22ls4r CL81 m228w/22ls4rHINGE COVER ASSY
AAN31022507 Base Assembly STAND M198WA/19LS4R/M208W HINGE COVER ASSY CKD
520 EBU36360202 Main Total Assembly 22LS4R-TA BRAND LP69C
521 ADV31008016 Frame Assembly 22LS4R CL-81 ETC METAL FRAME ASSY BB3 MFT EXT. TUNNER
ADV31008038 Frame Assembly 22LS4R . ETC 22LS4R METAL FRAME ASSY BB3 _NTSC [CKD]
522 MJH35991301 Supporter PRESS SBHG 1t NON SBHG M228W SUPPORT MERAL 1T
523 MGJ35722501 Plate,Shield PRESS SBHG 0.6T FRAME EGI M198W LAMP WIRE SHIELD (0.6T)
MGJ35722502 Plate,Shield PRESS SBHG 0.6T FRAME EGI M8W LAMP WIRE SHIELD (0.3T) CKD
530 EBR36362001 PCB Assembly CONTROL T.T LP69C 22LS4R AEUNLAX 22LS4R CONTOL T.T ASS’Y
531 MEY36500601 Knob MOLD ABS HF380 SUB CONTROL KNOB LS4R 19LS4R_22LS4R
580 6871TPT318G PCB Assembly,Power PLLM-M602C LG INNOTEK CO., LTD
590 EBR36362801 PCB Assembly LED & P/SW T.T LP69C 22LS4R AEUNLAX 22LS4R LED T.T ASS’Y
591 MFB36500901 Lens MOLD PMMA PLUS LENS 19LS4R 19LS4R_22LS4R INDICATOR
