Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a Cross-over cable or Null Modem cable.
Command Reference List
(Depending upon model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power* k a 00 to 01 15. Balance k t 00 to 64
02. Aspect Ratio k c (page 23)
16. Color
(Colour)
Temperature
x u 00 to 64
03. Screen Mute k d (page 23)
17. ISM Method
(Only Plasma
TV)
j p (page 25)
04. Volume
Mute
k e 00 to 01 18. Equalizer j v (page 25)
05. Volume
Control
k f 00 to 64
19. Energy
Saving
j q 00 to 05
06. Contrast k g 00 to 64
20. Tune
Command
m a (page 25)
07. Brightness k h 00 to 64
21. Channel
(Programme)
Add / Del(Skip)
m b 00 to 01
08. Color / Colour k i 00 to 64 22. Key m c Key Codes
09. Tint k j 00 to 64
23. Control
Backlight,
Control Panel
Light
m g 00 to 64
10. Sharpness k k 00 to 32
24. Input select
(Main)
x b (page 27)
11. OSD Select k l 00 to 01
25. 3D (Only
3D models)
x t (page 27)
12. Remote
Control Lock
Mode
k m 00 to 01
26. Extended
3D (Only 3D
models)
x v (page 28)
13. Treble k r 00 to 64
27. Auto
Configure
j u (page 28)
14. Bass k s 00 to 64
* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not executed
and treated as NG.
With RS232C cable, TV can communicate ka command in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.
