EXPLODED VIEW PARTS LIST
101 4810V01503A BRACKET,CRT 32FS3D AC05MA HIPS 40AF .
112 6335932003A CPT ASSEMBLY,W76ERS270XV1 N(+0.40G) 0G TINT DOUBLE
6335932003B CPT,ITCW76ERS270XV1 L 32INCH SUPER-SLIM 0.50G 4/3
120 6400VA0025F SPEAKER,FULLRANGE C163A01K1452 8OHM 15/20W 86DB OTHERS 32FS2D
150 EAP30771101 Coil,Degaussing 32INCH SUPER SLIM AT 110V ADD SPONGE
170 6868900001A EARTH,CRT 32INCH 2POINT TIN WIRE BRAID 144TS 32FS1D
174 64109UH002A POWER CORD,LP-208RW+YFH800-02 2400MM HOUSING BLACK
300 30919E0029B CABINET ASSEMBLY,32FS4D-UC NO BRAND
310 5020V01110A BUTTON,CONTROL 32FS2D-NA ABS, HF-380 6KEY .
320 320-062E SPRING,KNOB
330 5020V01111A BUTTON,POWER 32FS2D-NA ABS, HF-380 1KEY .
331 4810V01272B BRACKET,32FS2D AC05MA ABS, AF-303S POWER, BRACKET
400 3809900135B BACK COVER ASSEMBLY,32FS4D-UC
501 4810V01239A BRACKET,BOARD 32FS2D AC05MA HIPS 40AF .
503 4811V00359J BRACKET ASSEMBLY,REAR AV 32FS2D-UC AC05MB SUPER SLIM
504 351-008A LINK,POWER S/W FOR MC-97A CHASSIS
510 6871VSMZZ4D PCB Assembly,Sub CPT M.I AC05MB 32FS4D-UC AUSLLA CPT B/D
520 68719MM061B PCB ASSEMBLY,MAIN AC05MB 32FS2D-UC AUXLLAX M/I
68719MM061C PCB Assembly,MAIN1 M.I AC05MB 32FS4D-UC CANADA ACCLLA M/I
530 68719DM006A PCB ASSEMBLY,MAIN2 M.I AC05MB 32FS4D-UC AUSLLA MAIN2 ASSY
540 68719SM122A PCB ASSEMBLY,SUB AC05MA 32FS2D-NA AKRLLA HRS/CS
550 68719SM170B PCB ASSEMBLY,SUB AC05MA 32FS2D-UC AKRLLA DIGITAL NEC
560 68719SM153A PCB ASSEMBLY,SUB POWER M.I AC05MB 32FS2D-UB AUSLLAX POWER SW
570 68719SM067A PCB ASSEMBLY,SUB AC05MA 32FS2D AKRLLAK CONTROL
580 68719SM068B PCB ASSEMBLY,SUB AC05MA 32FS4D AKRLLAK LED/PRE AMP
600 68719SM121A PCB ASSEMBLY,SUB AC05MA 32FS2D-NA AKRLLA SIDE A/V
943 1PTF0403116 SCREW TAP TITE(P),TRUSS HEAD
No.
Part No.
Description
