EXPLODED VIEW PARTS LIST
No. PART NO. DESCRIPTION
120 EAB33496901 Speaker,Full Range 5B084 ND 10W 8OHM 82DB 120HZ 147 X 42 X 31
200 EAJ37543301 LCD,Module-TFT LC320WX4-SLD2 WXGA 1000:1(basic) 8ms(GTG),Zero RT Pol. 10000K LPL
210 MJH32520201 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, TOP (32LC4)
220 MJH32520401 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, BOTTOM (32LC4)
230 MJH32520501 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR POWER (32LC4)
240 MJH32520602 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, MIDDLE, V668, D2A
250 MJH32520702 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR MAIN , D2A
260 MGJ32973601 Plate PRESS SECC 1.6 SUPPORTER SBHG-A METAL JIG BOTTOM
300 ABJ32839404 Cabinet Assembly 32LC4R-MD LP78A 32” CABINET ASSY, H&C
400 ACQ31747004 Cover Assembly,Rear 32LC4R-TA LP78A 32” BACK COVER ASSY
401 MGJ32425801 Plate PRESS EGI T1.6 METAL HGI -
402 MCK32421902 Cover MOLD ABS 26LC4D-AA FOR N.AMERICA REAR AV BRACKET ABS FOR N.AMERICA
403 MCK32525101 Cover MOLD HIPS 51SF 32LC4R HIPS 51SF COVER, AV
430 AAN31752707 Base Assembly STAND 32LC4 LP78A ROUND STAND ASSY, HEAT&COOL
520 EBR37793101 PCB Assembly,Main MAIN T.T LP78A 32LC4R-MD . NTSC Main Total
530 EBR33882501 PCB Assembly,Sub SUB T.T LP78A H4 LCD Model . CONTROL
580 EAY38239801 Power Supply Assembly LGIT_32inch_(10000:1) FREE Tornado 32inch_(10000:1) LCD LGIT LCD
581 EBT36115101 Chassis Assembly POWER(SMPS) LP78A 32” LCD Model AC-Inlet Assembly
590 EBR38685401 PCB Assembly,Sub SUB T.T LP78A/B 32LC4R - Pre amp(500mm)
591 MES32421701 Indicator MOLD PMMA LED&PRE AMP 26LC4D-AA PMMA 2 PHY
600 EBR36653901 PCB Assembly,Sub SUB T.T LP78A 26/32 NON-EU SIDE AV
