7. RGB Input (PC/DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
PC DDC
1 640*350 31.469 70.08 25.17 DOS X
2 640*480 31.469 59.94 25.17 VESA(VGA) O
3 640*480 37.861 72.80 31.50 VESA(VGA) O
4 640*480 37.500 75.00 31.50 VESA(VGA) O
5 800*600 35.156 56.25 36.00 VESA(SVGA) O
6 800*600 37.879 60.31 40.00 VESA(SVGA) O
7 800*600 48.077 72.18 50.00 VESA(SVGA) O
8 800*600 46.875 75.00 49.50 VESA(SVGA) O
9 1024*768 48.363 60.00 65.00 VESA(XGA) O
10 1024*768 56.476 70.06 75.00 VESA(XGA) O
11 1024*768 60.023 75.02 78.75 VESA(XGA) O
12 1280*768 47.700 60.000 80.140 VESA(WXGA)
1360*768 47.720 59.799 84.750 VESA(WXGA)
1366*768 47.130 59.658 72.000 VESA(WXGA)
DTV
1 720*480 31.50 59.94 SDTV 480P
2 720*480 31.47 60.00 SDTV 480P
3 1280*720 44.96 59.94 HDTV 720P
4 1280*720 45.00 60.00 HDTV 720P
5 1920*1080 33.72 59.94 HDTV 1080I
6 1920*1080 33.75 60.00 HDTV 1080I
8. HDMI1 Input (PC/DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
PC DDC
1 640*480 31.469 59.94 25.17 VESA(VGA) O
2 640*480 37.861 72.80 31.50 VESA(VGA) O
3 640*480 37.500 75.00 31.50 VESA(VGA) O
4 800*600 35.156 56.25 36.00 VESA(SVGA) O
5 800*600 37.879 60.31 40.00 VESA(SVGA) O
6 800*600 48.077 72.18 50.00 VESA(SVGA) O
7 800*600 46.875 75.00 49.50 VESA(SVGA) O
8 1024*768 48.363 60.00 65.00 VESA(XGA) O
9 1024*768 56.476 70.06 75.00 VESA(XGA) O
10 1024*768 60.023 75.02 78.75 VESA(XGA) O
11 1280*768 47.700 60.00 80.140 VESA(WXGA) O
12 1360*768 47.720 59.799 84.750 VESA(WXGA) O
13 1366*768 47.130 59.658 72.000 VESA(WXGA) O
DTV
1 720*480 31.500 59.94 27.00 SDTV 480P
2 720*480 31.469 60.00 27.03 SDTV 480P
3 1280*720 44.96 59.94 HDTV 720P
4 1280*720 45.00 60.00 HDTV 720P
5 1920*1080 33.72 59.94 HDTV 1080I
6 1920*1080 33.75 60.00 HDTV 1080I
