- 9 -
10. General specifications (module)
No Item Value Unit Remark
1 Active Screen Size 800.4 (diagonal) mm 31.51 inches
2 Outline Dimension 760.0(H) x 450.0(V) x 42.8(D) mm
3 Pixel Pitch 170.25 x 510 x RGB um
4 Pixel Format 1366(H)x768(V) stripe arrangement
5 Color Depth 8bit 16.7 Mbit
6 Luminance ,White 500 (center 1 point typ) cd/m
2
7 Viewing Angle (CR>10) R/L 178(Typ), U/D 178(Typ) degree
8 Power Consumption 114.32 Watt
9 Weight 6.7 kg
10 Display Operating Mode Transmissive mode, normally black
11 Surface Treatment Hard coating (3H)
9. HDMI2 Input (DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1 720*480 31.500 59.94 27.00 SDTV 480P
2 720*480 31.469 60.00 27.03 SDTV 480P
3 1280*720 44.96 59.94 HDTV 720P
4 1280*720 45.00 60.00 HDTV 720P
5 1920*1080 33.72 59.94 HDTV 1080I
6 1920*1080 33.75 60.00 HDTV 1080I
11. Electro Optical Characteristic Specifications (module standard)
No Item Min Typ Max Unit Remark
1 Contrast Ratio(CR) 600 800
2 Surface Luminance, White 400 500 Cd/m
2
Full white
3 Luminance Variation 1.3 (
white/5P)
4 Response Time Rise Time 8 12 msec
Decay Time 10 14
G to G 8 14
5 Color coordinate RED X Typ 0.636 Typ
Y -0.03 0.343 +0.03
GREEN X 0.284
Y 0.615
BLUE X 0.144
Y 0.063
WHITE X 0.279
Y 0.292
6 Viewing Angle (CR>10) X axis right(ø=0) 85 89 degree
X axis left(ø=180) 85 89
Yaxis up (ø=90) 85 89
Z axis down(ø=270) 85 89
