LG 32LC7D - BACK COVER FOR WIRE ARRANGEMENT

PREPARATION
13
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
GG
Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
!
R
( )
600 mm
400 mm
R
( )
600 mm
(32 inches only: 200 mm)
400 mm
(32 inches only: 100 mm)
Plasma TV Model
LCD TV Model
For proper ventilation, allow a clearance of 4 inches on all four sides from the wall.
GG
Ensure adequate ventilation by following the clearance recommendations.
CAUTION
DESKTOP PEDESTAL INSTALLATION
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches
4 inches
Plasma TV Model
LCD TV Model
4 inches
