PREPARATION
36
PREPARATION
For 32/42/47/55SL80YR
Install the CABLE MANAGEMENT CLIP as
shown.
1
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
2
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
Install CABLE HOLDER as shown and bundle
the cables.
1
CABLE MANAGEMENT CLIP
CABLE HOLDER
GG
Do not hold the CABLE MANAGEMENT CLIP when moving the TV.
- If the TV is dropped, you may be injured or the product may be broken.
NOTE
FOR DESK-TYPE STAND
FOR WALL MOUNT
Install the CABLE MANAGEMENT CLIP as
shown.
1
CABLE MANAGEMENT CLIP
Connect the cables as necessary. To connect
additional equipment, see the EXTERNAL
EQUIPMENT SETUP section.
2
After Connecting the cables as necessary,
install CABLE HOLDER as shown and bundle
the cables. To connect additional equipment,
see the
EExxtteerrnnaall eeqquuiippmmeenntt SSeettuupp
sec-
tion.
1
CABLE HOLDER
FOR DESK-TYPE STAND
FOR WALL MOUNT
For 42/47SL90QR
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 36
