LG 32LD460 - Page 10

LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 10 -
5. Component Video Input (Y, CB/PB, CR/PR)
No
Specification
Remark
Resolution H-freq(kHz) V-freq(Hz)
1. 720x480 15.73 60.00 SDTV,DVD 480i
2. 720x480 15.63 59.94 SDTV,DVD 480i
3. 720x480 31.47 59.94 480p
4. 720x480 31.50 60.00 480p
5. 720x576 15.625 50.00 SDTV,DVD 625 Line
6. 720x576 31.25 50.00 HDTV 576p
7. 1280x720 37.50 50.00 HDTV 720p
8. 1280x720 44.96 59.94 HDTV 720p
9. 1280x720 45.00 60.00 HDTV 720p
10. 1920x1080 28.125 50.00 HDTV 1080i
11. 1920x1080 33.75 60.00 HDTV 1080i
12. 1920x1080 33.72 59.94 HDTV 1080i
13. 1920x1080 56.250 50 HDTV 1080p
14. 1920x1080 67.43/67.5 59.94/60 HDTV 1080p
No
Specification
Proposed Remark
Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)
1. 720*400 31.468 70.08 28.321 For only DOS mode
2. 640*480 31.469 59.94 25.17 VESA
Input 848*480 60Hz, 852*480 60Hz
-> 640*480 60Hz Display
3. 800*600 37.879 60.31 40.00 VESA
4. 1024*768 48.363 60.00 65.00 VESA(XGA)
5. 1280*768 47.78 59.87 79.5 WXGA
6. 1360*768 47.72 59.8 84.75 WXGA
7. 1280*1024 63.595 60.0 108.875 SXGA FHD model
8. 1920*1080 66.587 59.93 138.625 WUXGA FHD model
6. RGB (PC)
No. Item Min Typ Max Remark
1. Cool White Balance,X axis 0.267 0.269 0.271 DQA : ±0.015 PSM: Vivid,
White Balance,Y axis 0.271 0.273 0.275 White (85IRE)
2. Medium White Balance,X axis 0.283 0.285 0.287 Color Temp : C50 -> Cool
White Balance,Y axis 0.291 0.293 0.295 0 -> Medium
3. Warm White Balance,X axis 0.311 0.313 0.315 W50 -> Warm
White Balance,Y axis 0.327 0.329 0.331
4.2. Chroma (Vivid)
- except “RGB PC Mode PSM: Standard, Color Temperature:Medium”
** The W/B Tolerance is ±0.002 for Adjustment, but for DQA ±0.015
