Pin Number Pin Name Signal Name
1P60/SCL0 NEC_SCL
2P61/SDA0 NEC_SDA
3 P62/ EX S CL 0 NEC_EEPROM_SCL
4P63 NEC_EEPROM _SDA
5 P33/ TI51/ TO51/ INTP4 CEC_REMOTE_NEC
6P75 POWER_ON/OFF2_1
7P74 AMP_MUTE
8 P73/ KR3 MODEL1_OPT_0
9 P72/ KR2 SOC_RESET
10 P71/ KR1 INV_CTL
11 P70/ KR0 MODEL1_OPT_1
12 P32/ INTP3/ OC D1B OCD1B,RF_RESET
13 P31/ INTP2/ OC D1A RF_ENABLE,OCD1A
14 P30/ INTP1 POWER_DET
15 P17/ TI 50/ TO50 LED_B/LG_LOGO
16 P16/ TOH1/ INTP 5 IR
17 P 15/ TOH0 LED_R/BUZZ
18 P 14/ RX D6 NEC_ISP_Rx
19 P 13/ TX D6 NEC_ISP_Tx
20 P 12/ SO10 POWER_ON/OFF2_2
21 P11/ SL 10/ RX D0 NEC_RXD
22 P10/ SC K10/ TX D0 NEC_TXD
25 ANI7/ P27 KEY 1
26 ANI6/ P26 KEY 2
27 ANI5/ P25 SIDE_HP_MUTE
28 ANI4/ P24 OLP
29 ANI3/ P23 POWER_ON/OFF1
30 ANI2/ P22 MODEL1_OPT_2
31 ANI1/ P21 MODEL1_OPT_3
32 P20/ ANI 0 SCART1_MUTE
33 P130 WIRELE SS_SW_C TRL
34 P01/ TI010/ TO00 EDID_WP
35 P00/ TI000 OPC_EN
36 P140/ PC L / INTP6 RL_ON
37 P120/ INTP0/ E X L V I KE Y 2
38 P 41 WIRELESS_PWR_EN
39 P 40 WIRELESS_DETECT
40 RE S ET MICOM_RESET
43 FL M D0 FLMD0
GPIO Block(MICOM)
GPIO Block(MICOM)
