POWER Block (+3.5V_ST)
POWER Block (+3.5V_ST)
P403 or P402
(#9~12), (#10,12)
+3.3V_ST
+1.26V_VDDC
+1.5V_DDR
IC403
MP2212DN
(DCDC)3A
IC407
MP2212DN
(DCDC)3A
IC1101
MAX3232CDR
(RS-232C)
+3.5V_ST
L404
IC1, IC2
H5PS5162FFR-S6C
DDR2
IC1002
UPD78F0513AGA
(Micom)
IC1001
M24C16-WMN6T
(EEPROM)
IC408
NCP803SN293
(RESET IC)
Power_DET
IC100
Main SOC
S7(LGE101D)
& S7 T(LGE105)
