- 13 -
(3) Execute ‘Download_CS.vi2c’ program in PC, then a
main widow will be opened.
(4) Click "GO" button
(5) Double click the blue box and confirm "Bootloader
Version" as 40.
(6)Click the "Erase Flash" button
(7) Double click the download file low then, "edit"
window will be opened
(8) Chick the choice button I n the "edit window", then
"file choice window’ will be opened
(9) Choose the Hex file in folder and execute
downloading with click "open button"
(10) Click OK button at the "edit window"
(11) Under Downloading progress
(12) If download is failed, for example "No acknowledge
from slave", execute download again from (1)
Double click
If you don’t push the "go",
the Hex file would not be
downloaded although the
download proceeds normally
at first glance
To Next Page
