No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 720*400 31.468 70.08 28.321 HDCP
2 640*480 31.469 59.94 25.17 VESA HDCP
37.684 75.00 31.50
3 800*600 37.879 60.31 40.00 VESA HDCP
46.875 75.00 49.50
4 832*624 49.725 74.55 57.283 Macintosh HDCP
5 1024*768 48.363 60.00 65.00 VESA(XGA) HDCP
56.470 70.00 75.00
60.123 75.029 78.75
6 1280*768 47.78 59.87 79.5 WXGA HDCP
7 1360*768 47.72 59.8 84.75 WXGA HDCP
8 1366*768 47.56 59.6 84.75 WXGA HDCP
9 1440*900 55.5 59.90 88.750 WXGA 19LG3000-ZA only
10 1400*1050 64.744 59.948 101.00 WSXGA 22LG3000-ZA only
11 1680*1050 65.16 59.94 147.00 WSXGA 22LG3000-ZA only
12 1280*1024 63.595 60.0 108.875 SXGA FHD Model only, HDCP
13 1920*1080 66.647 59.988 138.625 WUXGA FHD Model only, HDCP
9. HDMI PC
8. HDMI DTV
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1 720*480 15.734 / 15.6 59.94 / 60 27.00 SDTV 480I
2 720*480 31.469 / 31.5 59.94 / 60 27.00/27.03 SDTV 480P
3 720*576 15.625 50 27(54) SDTV 576I
4 720*576 31.25 50 54 SDTV 576P
5 1280*720 37.500 50 74.25 HDTV 720P
6 1280*720 44.96 / 45 59.94 / 60 74.17/74.25 HDTV 720P
7 1920*1080 33.72 / 33.75 59.94 / 60 74.17/74.25 HDTV 1080I
8 1920*1080 28.125 50.00 74.25 HDTV 1080I
9 1920*1080 26.97 / 27 23.97 / 24 74.17/74.25 HDTV 1080P
10 1920*1080 33.716 / 33.75 29.976 / 30.00 74.25 HDTV 1080P
11 1920*1080 56.250 50 148.5 HDTV 1080P
12 1920*1080 67.43 / 67.5 59.94 / 60 148.35/148.50 HDTV 1080P
