LG 32LX2D Service Manual

- 28 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
3091TKE037H CABINET ASSEMBLY, 32LX2D-AA BRAND CABINET ASSY
6304FLP288A
LCD(LIQUID CRYSTAL DISPLAY), LC320W01-SL01 LG PHILPS TFT COLOR WXGA AIODC SPEC UP LEAD FREE
3809TKE030V BACK COVER ASSEMBLY, 32LX2D-AA DTV 3808TKE025 SET
3043TKK252A TILT SWIVEL ASSEMBLY, 32LX2D-UA STAND ASSY
3550TKK881C COVER, 32LX2D NO SPRAY REAR AV COVER
4951TKS222G METAL ASSEMBLY, FRAME METAL ASSY 32LX1D-NA
6400GESF01A
SPEAKER,FULLRANGE, C112A02K1450 ESTEC FULL-RANGE(GENERAL) 8OHM 10/15W .DB 110 32LG10
6871TPT303B PWB(PCB) ASSEMBLY,POWER, DU/DN/DI-32LP10 POWER TOTAL BRAND DU(DCR) COMM - SH(D112)
33139D3012A MAIN TOTAL ASSEMBLY, 32LX2D BRAND AL-05PB
68719ST791A PWB(PCB) ASSEMBLY,SUB, SUB T.T AB 32LX2D-AA ALAULVX TUNER
4951TKK238J METAL ASSEMBLY, FRAME, REAR 32LX2D-AA
68719ST790A PWB(PCB) ASSEMBLY,SUB, SUB T.T AB 32LX2D-AA ALAULVX CONTROL KEY
68719ST789A PWB(PCB) ASSEMBLY,SUB, SUB T.T AB 32LX2D-AA ALAULVX LIGHT&IR ETC
4950TKA210A METAL, SIDE BRACKET 32LX1D LPL MODULE
33139D3011A MAIN TOTAL ASSEMBLY, 32LX2D-AA BRAND AL-05PB
68719ST788A PWB(PCB) ASSEMBLY,SUB, SUB T.T AB 32LX2D-AA ALAULVX SIDE COMP SUB TOTAL
4815TKK046J SHIELD ASSEMBLY, REAR SHIELD ASSY 32LX2D-AA
3551TKK589U COVER ASSEMBLY, DTV 32LX2D-AA REAR AV BRACKET ASSY
010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170
180
