LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C222 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C231 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C234 0CH5030K116 3PF 50V 0.5 PF NP0 2012 R/T
C235 0CH5030K116 3PF 50V 0.5 PF NP0 2012 R/T
C236 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C238 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C240 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C256 0CH5030K116 3PF 50V 0.5 PF NP0 2012 R/T
C257 0CH5030K116 3PF 50V 0.5 PF NP0 2012 R/T
C259 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C260 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C261 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C308 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C309 0CK105DK94A "1UF 2012 50V 80%,-20% R/TP"
C310 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C357 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C358 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C359 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C360 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C362 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C363 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C364 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C365 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C366 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C367 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C369 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C371 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C372 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C374 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C375 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C378 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C379 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C380 0CH5470K416 47PF 50V 5% NP0 2012 R/TP
C382 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C383 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C386 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C403 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C404 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C406 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C409 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C410 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C411 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C412 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C414 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C415 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C416 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C417 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C418 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C419 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C420 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C421 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C423 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C425 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C427 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C428 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C429 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C430 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C431 0CK105DK94A "1UF 2012 50V 80%,-20% R/TP"
C432 0CK105DK94A "1UF 2012 50V 80%,-20% R/TP"
C433 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C434 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C435 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C436 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C437 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C438 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C439 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C440 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C441 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C442 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C445 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C451 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C452 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C453 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C454 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C456 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C457 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C458 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C459 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C460 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C463 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C464 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C465 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C466 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C467 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C470 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C471 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C472 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C473 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C474 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C475 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C476 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C477 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C478 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C479 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C480 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C481 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C482 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C483 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C484 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C485 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C486 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C487 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C488 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C489 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C490 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C491 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C492 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C493 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C494 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C495 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C496 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C497 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C498 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C499 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C500 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C501 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C502 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C503 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C504 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C505 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C506 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C507 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C508 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C509 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
- 35 -
