LG 32LX570M Easy Setup Guide

27
ENGLISH
* Tune Command Examples:
1 Tune to the digital antenna (ISDB-T) channel 17-1 .
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 17 = 00 11
Data 03 & 04 = Minor/Branch is 1 = 00 01
Data 05 = Digital Antenna TV = 02
Total = ma 00 00 00 11 00 01 02
2. Tune to the BS (ISDB-BS) channel 30.
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Don’t Care = 00 00
Data 05 = Digital BS TV = 07
Total = ma 00 00 00 1E 00 00 07
* This feature is varied based on the model.
Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]
[Data 02][Data 03][Data 04][Data 05]
[x][a][ ][Set ID][ ][NG][Data 00][x]
21. Channel(Programme) Add / Del(Skip) (Command:
m b)
▶ To skip current channel(programme) for next time.
Transmission [m][b][ ][Set ID][ ][Data][Cr]
Data 00 : Del(ATSC,ISDB) / Skip(DVB)
01 : Add
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* Set the saved channel status to del(ATSC, ISDB) /
skip(DVB) or add.
22. Key (Command : m c)
▶ To send IR remote key code.
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Data Key code - page 18.
Ack [c][ ][Set ID][ ][OK/NG][Data][x]
23. Control Backlight (Command: m g)
• For LCD TV / LED TV
▶ To control the backlight.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
• For Plasma TV
▶ To control the panel light.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
24. Input select (Command : x b)
(Main Picture Input)
▶ To select input source for main picture.
Transmission [x][b][ ][Set ID][ ][Data][Cr]
Data
00 : DTV
02 : Satellite DTV
ISDB-BS (Japan)
03 : ISDB-CS1 (Japan)
04 : ISDB-CS2 (Japan)
11 : CATV
01 : CADTV
10 : ATV
20 : AV or AV1 21 : AV2
40 : Component1
60 : RGB
41 : Component2
90 : HDMI1
92 : HDMI3
91 : HDMI2
93 : HDMI4
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* This function depends on model and signal.
25. 3D(Command: x t) (only 3D models)
(Depending upon model)
▶ To change 3D mode for TV.
Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01]
[ ][Data 02][ ][Data 03][Cr]
* (Depending upon model)
Data Structure
[Data 00] 00 : 3D On
01 : 3D Off
02 : 3D to 2D
03 : 2D to 3D
[Data 01] 00 : Top and Bottom
01 : Side by Side
02 : Check Board
03 : Frame Sequential
04 : Column interleaving
05 : Row interleaving
[Data 02] 00 : Right to Left
01 : Left to Right
[Data 03] 3D Effect(3D Depth) : Min : 00 - Max : 14
(*transmit by Hexadecimal code)

LG 32LX570M Specifications

General

Screen shape	Flat
Response time	9 ms
Display diagonal	31.8 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1200:1
Display diagonal (metric)	81.28 cm
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1366 x 768
Motion interpolation technology	-
3D	No
Cable lock slot type	Kensington
RJ-12 ports quantity	1
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Smart modes	Cinema, Energy saving, Game, Sports, Standard, Vivid
Sound modes	Game, Movie, Music, News, Sports, Standard
Audio decoders	Dolby Digital
RMS rated power	10 W
Number of speakers	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Audio formats supported	AAC, AC3, EAC3, MP3, PCM
Image formats supported	JPG
Picture processing technology	LG Triple XD Engine
Panel mounting interface	200 x 200 mm
AC input voltage	120 V
Power consumption (standby)	0.5 W
Power consumption (typical)	42 W
Package depth	114.3 mm
Package width	800.1 mm
Package height	510.54 mm
Package weight	6622.45 g
Certification	UL, FCC, cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (without stand)	55.88 mm
Width (without stand)	734.06 mm
Height (without stand)	436.88 mm
Weight (without stand)	5307.03 g
