LG 37LC7D - Page 22

- 22 -
- Video signal path for Composite
Comp1_Y 8(3A) Comp1_Pb 11(2A) Comp1_Pr 16(1A)
Comp2_Y 9(3B)
Comp2_Pb 14(2B) Comp2_Pr 1(1B)
2 12 7
SW1 SW2 SW3
6(Out3) Comp_Y 5(Out2) Comp_Pb 3(Out1) Comp_Pr
L H
8(3A) 11(2A) 16(1A)
RGB_G 9(3B)
RGB_B 14(2B) RGB_R 1(1B)
2 12 7
SW1 SW2 SW3
6(Out3) Y/G to LPF 5(Out2) Pb/B to LPF 3(Out1) Pr/R to LPF
L H
IC5001
IC5002
Y/G 3(YIN) Pb/B 5(PBIN) Pr/R 7(PBIN)
1(EXT_SYNC) 18(SYNC_IN)
16 Comp_Y 15 Comp_Pb 14 Comp_Pr
44(GIN+) 43(SOGIN) 41(BIN+) 46(RIN+)
IC704
IC4009
RGB_G
H Sync
7404
V Sync
RGB_B RGB_R
BCM3550
GPIO
GPIO for sync selection
HD-DVI
Data [24]
H sync/V sync
/DE/Clock
H,V Sync/Clock
RGB_HS
GPIO for sync selection
RGB_HS
RGB_VS
RGB_HS RGB_VS
GPIO
GPIO for Component 1
GPIO
GPIO for Component 2
GPIO for Component 2
GPIO for Component 1
IC1001
FMS6407
MST3361
MM1731
MM1732
DATA_OUT H/V/DE/CLK
LPF_CTRL0 LPF_CTRL1
LPF_CTRL0
LPF_CTRL1
