4. Digital RF Trouble Shooting guide
Check RF Cable
Check IIC Sig nal
TU3001 #3, 4Pin
Check IIC line and level shifter circuit
Y
N
Check Tun er 5V Power
L3000
Check L3000
Y
N
Y
Check X201
and application circuit
Check IF Signal
TU3001 #10, 11 Pin
Check tun er ap plication circuit or
replace tun er.
N
Y
Replace X201
N
Y
Replace IC101
Replace IC5000
N
Y
Replace L3000
