10. HDMI Audio in Trouble Shooting guide
11. Audio out Trouble shooting guide
Check input signal format.
Is it supported?
Check JK800/JK801/JK802
Can you see the normal waveform?
Replace JK800/JK801/JK802
Y
N
Check AC cable for damage
For d amage or open conductor
Y
Y
Check Audio AMP output
L5503,L5504,L5505,L5506
Y
Replace L5503,L5504,L5505,L5506
N
This board has big problem because Main chip (Mstar) have some troubles.
After checking thoroughly all path once again, You should decide to replace Mstar or not.
Check the o utput of Mstar(IC101).
Measure wavefo rm at R123, IC5600(Pin23, 24).
because it’s mo re easy to ch eck. Can you see the n ormal signal?
YES
NO
This bo ard has big p roblem because Main chip (MStar) have some troubles.
After checking thoroughly all path once again,
You should decide to replace Mstar or not.
Check Audio AMP output L5503,L5504,L5505,L5506
Can you see the no rmal waveform?
NO
YES
After checking the Power & I2C & Reset of this chip ,
you should decide to replace this or not.
Check the speaker output wafer P5600.
Can you see the no rmal waveform?
NO
YES
After checking aud io signal line, you sh ould decide to replace item or not.
Check the connector & Speaker
To Next Page
