LG 42LC7D Service Manual

- 8 -
8. HDMI/DVI input (DTV / PC)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Remarks
DTV
1. 720*576 31.25 50.00 27.00 SDTV 576p
2. 720*480 31.47/31.50 59.94/60.00 27.00 SDTV 480p
3. 1280*720 44.96/45.00 59.94/60.00 74.25 HDTV 720P
4. 1280*720 37.50 50.00 74.25 HDTV 720P
5. 1920*1080 33.72/33.75 59.94/60.0 74.25 HDTV 1080i
6. 1920*1080 28.125 50.00 74.25 HDTV 1080i
7. 1920*1080 67.432/67.500 59.939/60 148.5 HDTV 1080P
8. 1920*1080 56.25 50 148.5 HDTV 1080P
9. 1920*1080 26.97/27.000 23.97/24.000 74.25 HDTV 1080P
10. 1920*1080 33.71/33.75 29.97/30.000 74.25 HDTV 1080P
PC
11. 640*480 31.469 59.94 25.17 VESA(VGA)
12. 640*480 37.861 72.80 31.50 VESA(VGA)
13. 640*480 37.500 75.00 31.50 VESA(VGA)
14. 800*600 35.156 56.25 36.00 VESA(SVGA)
15. 800*600 37.879 60.31 40.00 VESA(SVGA)
16. 800*600 48.077 72.18 50.00 VESA(SVGA)
17. 800*600 46.875 75.00 49.50 VESA(SVGA)
18. 1024*768 48.363 60.00 65.00 VESA(XGA)
19. 1024*768 56.476 70.06 75.00 VESA(XGA)
20. 1024*768 60.023 75.02 78.75 VESA(XGA)
21. 1280*768 47.776 59.870 79.5 CVT(WXGA)
22. 1360*768 47.720 59.799 84.750 CVT(WXGA)
23. 1366*768 47.13 59.65 72.00
7. RGB input (PC)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Remarks
1. 640*350 31.468 70.09 25.17 EGA
2. 640*480 31.469 59.94 25.17 VESA(VGA)
3. 640*480 37.861 72.80 31.50 VESA(VGA)
4. 640*480 37.500 75.00 31.50 VESA(VGA)
5. 800*600 35.156 56.25 36.00 VESA(SVGA)
6. 800*600 37.879 60.31 40.00 VESA(SVGA)
7. 800*600 48.077 72.18 50.00 VESA(SVGA)
8. 800*600 46.875 75.00 49.50 VESA(SVGA)
9. 1024*768 48.363 60.00 65.00 VESA(XGA)
10. 1024*768 56.476 70.06 75.00 VESA(XGA)
11. 1024*768 60.023 75.02 78.75 VESA(XGA)
12. 1280*768 47.776 59.870 79.5 CVT(WXGA)
13. 1360*768 47.720 59.799 84.750 CVT(WXGA)
14. 1366*768 47.13 59.65 72.00
