LG 42LE5350 - Page 79

20. Trouble shooting - Ethernet connection error
Replace one of L8204
& Recheck
N
Check LAN Port Power
L8204
Y
Check LAN Port LED
N
Replace one of LAN Port
& Recheck
Y
Maybe BCM3549 LAN PHY block
has problems. Replace It
N
Check LAN Cable
Recheck
LAN Cable
N
Y
Check MAC Address
Replace
Main B/D
N
