LG 42LN541C Service Manual

- 11 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.1.6. Reference
(White Balance Adj. coordinate and color
temperature)
▪ Luminance: 204 Gray, 80IRE
▪ Normal line
model: (normal line)LN5xxx, LA6xxx, LA7xxx, LA8xxx
▪ Stand a rd colo r c o ordin a te and t emper a ture usi n g
CA-210(CH-14) – by aging time
H/R Time(Min)
Cool Medium Warm
x y x x y x
271 270 286 289 314 318
1 0-2 281 287 296 306 321 331
2 3-5 280 285 295 304 320 329
3 6-9 278 284 293 303 318 328
4 10-19 276 281 291 300 316 325
5 20-35 275 277 290 296 315 321
6 36-49 274 274 289 293 314 318
7 50-79 273 272 288 291 313 316
8 80-119 272 271 287 290 312 315
9 Over 120 271 270 286 289 311 314
▪ Aging chamber line
(Aging chamber) Model : LN5xxx, LA6xxx, LA7xxx, LA8xxx
▪ Stand a rd colo r c o ordin a te and t emper a ture usi n g
CA-210(CH-14) – by aging time
H/R Time(Min)
Cool Medium Warm
x y x x y x
271 270 286 289 314 318
1 0-5 283 292 298 311 323 336
2 6-10 282 290 297 309 322 334
3 11-20 280 288 295 307 320 332
4 21-30 277 284 292 303 317 328
5 31-40 275 279 290 298 315 323
6 41-50 274 275 289 294 314 319
7 51-80 273 272 288 291 313 316
8 81-119 272 271 287 290 312 315
9 Over 120 271 270 286 289 311 314
(Aging chamber) Model : LN5xxx, LA6xxx, LA7xxx, LA8xxx
▪ Stand a rd colo r c o ordin a te and t emper a ture usi n g
CA-210(CH-14) – by aging time
H/R Time(Min)
Cool Medium Warm
x y x x y x
271 270 286 289 314 318
1 0-5 280 285 295 304 320 329
2 6-10 276 280 291 299 316 324
3 11-20 272 275 287 294 312 319
4 21-30 269 272 284 291 309 316
5 31-40 267 268 282 287 307 312
6 41-50 266 265 281 284 306 309
7 51-80 265 263 280 282 305 307
8 81-119 264 261 279 280 304 305
9 Over 120 264 260 279 279 304 304
5.2. Option selection per country
5.2.1. Overview
(1) Tool option selection is only done for models in Non-USA
North America due to rating
(2) Applied model: LA3AA Chassis applied to CANADA and
MEXICO
5.2.2. Country Group selection
(1) Press ADJ key on the Adj. R/C, and then select Country
Group Menu
(2) Depending on destination, select US, then on the lower
Country option, select US, CA, MX.
Selection is done using +, - KEY
5.2.3. Tool Option inspection
▪ Press Adj. key on the Adj. R/C, then select Tool option
Model Module Tool 1 Tool 2 Tool 3 Tool 4 Tool 5 Tool 6 Commercial
32LN541C-UA ROW (LGD) 16452 2321 9873 29612 14340 1 71
39LN541C-UA POLA (LGD)
42LN541C-UA ROW (LGD) 16455 2321 9873 29612 14340 1 71
47LN541C-UA ROW (LGD) 16456 2321 9873 29612 14340 1 71
55LN541C-UA POLA (LGD) 16458 2321 10001 29612 14340 1 71
※ Tool option can be reconstructed by Software
5.3. Ship-out mode check (In-stop)
- After final inspection, press In-Stop key of the Adj. R/C and
check that the unit goes to Stand-by mode
