LG 42LX330C User Manual

20
ENGLISH
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command Reference List
(Depending upon model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power* k a 00 to 01 15. Balance k t 00 to 64
02. Aspect Ratio k c (page 22)
16. Color
(Colour)
Temperature
x u 00 to 64
03. Screen Mute k d (page 22)
17. ISM Method
(Only Plasma
TV)
j p (page 24)
04. Volume
Mute
k e 00 to 01 18. Equalizer j v (page 24)
05. Volume
Control
k f 00 to 64
19. Energy
Saving
j q 00 to 05
06. Contrast k g 00 to 64
20. Tune
Command
m a (page 24)
07. Brightness k h 00 to 64
21. Channel
(Programme)
Add/Del(Skip)
m b 00 to 01
08. Color/Colour k i 00 to 64 22. Key m c Key Codes
09. Tint k j 00 to 64
23. Control
Backlight,
Control Panel
Light
m g 00 to 64
10. Sharpness k k 00 to 32
24. Input select
(Main)
x b (page 26)
11. OSD Select k l 00 to 01
25. 3D (Only
3D models)
x t (page 26)
12. Remote
Control Lock
Mode
k m 00 to 01
26. Extended
3D (Only 3D
models)
x v (page 27)
13. Treble k r 00 to 64
27. Auto
Configure
j u (page 27)
14. Bass
k s 00 to 64
* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not executed
and treated as NG.
With RS232C cable, TV can communicate ka command in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.

LG 42LX330C Specifications

General

Screen shape	Flat
Response time	8 ms
Display diagonal	42.1 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Supported video modes	1080i, 1080p
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	107.1 cm
Screen format adjustments	4:3, 16:9, Zoom
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	-
3D	No
Cable lock slot type	Kensington
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Sound modes	Game, Movie, Music, Sports, Standard
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Audio formats supported	AAC, AC3, HE-AAC, LPCM, MP3
Video formats supported	DIVX
Picture processing technology	Samsung Wide Color Enhancer
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	39 W
Package depth	152.4 mm
Package width	1059 mm
Package height	660.4 mm
Package weight	11610 g
Certification	cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (with stand)	218.4 mm
Height (with stand)	612.1 mm
Weight (with stand)	9480 g
Depth (without stand)	55.88 mm
Width (without stand)	960.1 mm
Height (without stand)	566.4 mm
Weight (without stand)	9208 g
