LG 42LX330C User Manual

26
ENGLISH
* Tune Command Examples:
1 Tune to the digital antenna (ISDB-T) channel 17-1 .
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 17 = 00 11
Data 03 & 04 = Minor/Branch is 1 = 00 01
Data 05 = Digital Antenna TV = 02
Total = ma 00 00 00 11 00 01 02
2. Tune to the BS (ISDB-BS) channel 30.
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Don’t Care = 00 00
Data 05 = Digital BS TV = 07
Total = ma 00 00 00 1E 00 00 07
* This feature is varied based on the model.
Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]
[Data 02][Data 03][Data 04][Data 05]
[x][a][ ][Set ID][ ][NG][Data 00][x]
21. Channel(Programme) Add/Del(Skip) (Command:
m b)
▶ To skip current channel(programme) for next time.
Transmission [m][b][ ][Set ID][ ][Data][Cr]
Data 00 : Del(ATSC,ISDB)/Skip(DVB)
Data 01 : Add
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* Set the saved channel status to del(ATSC, ISDB)/
skip(DVB) or add.
22. Key (Command: m c)
▶ To send IR remote key code.
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Data Key code - page 17.
Ack [c][ ][Set ID][ ][OK/NG][Data][x]
23. Control Backlight (Command: m g)
• For LCD TV / LED TV
▶ To control the backlight.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
• For Plasma TV
▶ To control the panel light.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
24. Input select (Command: x b)
(Main Picture Input)
▶ To select input source for main picture.
Transmission [x][b][ ][Set ID][ ][Data][Cr]
Data
00 : DTV
02 : Satellite DTV
ISDB-BS (Japan)
03 : ISDB-CS1 (Japan)
04 : ISDB-CS2 (Japan)
11 : CATV
01 : CADTV
10 : ATV
20 : AV or AV1 21 : AV2
40 : Component1
60 : RGB
41 : Component2
90 : HDMI1
92 : HDMI3
91 : HDMI2
93 : HDMI4
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* This function depends on model and signal.
25. 3D(Command: x t) (only 3D models)
(Depending upon model)
▶ To change 3D mode for TV.
Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01]
[ ][Data 02][ ][Data 03][Cr]
* (Depending upon model)
Data Structure
[Data 00] 00 : 3D On
01 : 3D Off
02 : 3D to 2D
03 : 2D to 3D
[Data 01] 00 : Top and Bottom
01 : Side by Side
02 : Check Board
03 : Frame Sequential
04 : Column interleaving
05 : Row interleaving
[Data 02] 00 : Right to Left
01 : Left to Right
[Data 03] 3D Effect(3D Depth): Min : 00 - Max : 14
(*transmit by Hexadecimal code)

LG 42LX330C Specifications

General

Screen shape	Flat
Response time	8 ms
Display diagonal	42.1 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Supported video modes	1080i, 1080p
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	107.1 cm
Screen format adjustments	4:3, 16:9, Zoom
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	-
3D	No
Cable lock slot type	Kensington
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Sound modes	Game, Movie, Music, Sports, Standard
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Audio formats supported	AAC, AC3, HE-AAC, LPCM, MP3
Video formats supported	DIVX
Picture processing technology	Samsung Wide Color Enhancer
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	39 W
Package depth	152.4 mm
Package width	1059 mm
Package height	660.4 mm
Package weight	11610 g
Certification	cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (with stand)	218.4 mm
Height (with stand)	612.1 mm
Weight (with stand)	9480 g
Depth (without stand)	55.88 mm
Width (without stand)	960.1 mm
Height (without stand)	566.4 mm
Weight (without stand)	9208 g
