LG 42PC1RV-ZJ Service Manual

- 34 -
LOCA. NO PART NO DESCRIPTION
C335
C336
C337
C338
C339
C340
C343
C345
C346
C347
C350
C351
C352
C400
C401
C406
C407
C408
C409
C410
C411
C412
C413
C414
C415
C416
C417
C419
C420
C421
C424
C425
C426
C429
C430
C500
C502
C503
C506
C507
C508
C509
C511
C512
C513
C514
C515
C516
C517
C517
C518
C519
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CE107WF6DC
0CE476WF6DC
0CE226WF6DC
0CE476WF6DC
0CK104CF56A
0CK103CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CE476WF6DC
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK102CK56A
0CK102CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK102CK56A
0CK104CK56A
0CK102CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK822CK46A
0CK823CF56A
0CE477WF6DC
0CE477WF6DC
0CE475SK6DC
0CK103CK56A
0CK103CK56A
0CC270CK41A
0CC270CK41A
0CK103CK56A
0CC101CK41A
0CE477WF6DC
0CK273CK56A
0CK103CK56A
0CK104CK56A
0CK103CK56A
0CK273CK56A
0CK104CK56A
0CE107WF6DC
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
100UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
22UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
0.1UF 1608 16V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
47UF MVK 16V 20% R/TP(SMD) SMD
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
1000PF 1608 50V 0.1 R/TP X7R
1000PF 1608 50V 0.1 R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
1000PF 1608 50V 0.1 R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
1000PF 1608 50V 0.1 R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
8.2NF 1608 50V 5% X7R R/TP
82NF 1608 16V 10% X7R R/TP
470UF MVK 16V 20% SMD R/TP(SMD)
470UF MVK 16V 20% SMD R/TP(SMD)
4.7UF MVG 50V 20% SMD R/TP
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
27PF 1608 50V 5% R/TP NP0
27PF 1608 50V 5% R/TP NP0
0.01UF 1608 50V 10% R/TP X7R
100PF 1608 50V 5% R/TP NP0
470UF MVK 16V 20% SMD R/TP(SMD)
27000PF 1608 50V 10% X7R R/TP
0.01UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
27000PF 1608 50V 10% X7R R/TP
0.1UF 1608 50V 10% R/TP X7R
100UF MVK 16V 20% R/TP(SMD) SMD
LOCA. NO PART NO DESCRIPTION
C520
C521
C522
C523
C524
C525
C605
C606
C607
C608
C609
C610
C611
C612
C613
C614
C615
C616
C617
C618
C619
C620
C621
C622
C623
C624
C625
C626
C627
C628
C629
C630
C631
C632
C633
C634
C635
C636
C637
C638
C643
C645
C647
C648
C649
C650
C651
C652
C653
C654
C655
C657
0CK104CK56A
0CC271CK41A
0CC271CK41A
0CE476WK6DC
0CK104CK56A
0CE107WF6DC
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK103CK56A
0CK474CH94A
0CK474CH94A
0CE475WJ6DC
0CK474CH94A
0CK474CH94A
0CK474CH94A
0CK103CK56A
0CK474CH94A
0CK474CH94A
0CK474CH94A
0CE335WK6D8
0CK104CK56A
0CK332CK56A
0CK332CK56A
0CK332CK56A
0CK332CK56A
0CK104CK56A
0CK682CK51A
0CC560CK41A
0CC560CK41A
0CK682CK51A
0CK103CK56A
0CC220CK41A
0CE226WF6DC
0.1UF 1608 50V 10% R/TP X7R
270PF 1608 50V 5% R/TP NP0
270PF 1608 50V 5% R/TP NP0
47UF MVK 50V 20% R/TP(SMD) SMD
0.1UF 1608 50V 10% R/TP X7R
100UF MVK 16V 20% R/TP(SMD) SMD
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
4.7UF MVK 35V 20% R/TP(SMD) SMD
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.01UF 1608 50V 10% R/TP X7R
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
3.3UF MVK,RC 50V 20% SMD TAPPING
0.1UF 1608 50V 10% R/TP X7R
3.3NF 1608 50V 10% R/TP X7R
3.3NF 1608 50V 10% R/TP X7R
3.3NF 1608 50V 10% R/TP X7R
3.3NF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
6800PF 1608 50V 10% R/TP B(Y5P)
56PF 1608 50V 5% R/TP NP0
56PF 1608 50V 5% R/TP NP0
6800PF 1608 50V 10% R/TP B(Y5P)
0.01UF 1608 50V 10% R/TP X7R
22PF 1608 50V 5% R/TP NP0
22UF MVK 16V 20% R/TP(SMD) SMD
For Capacitor & Resistors,
the charactors at 2nd and 3rd
digit in the P/No. means as
follows;
CC, CX, CK, CN : Ceramic
CQ : Polyestor
CE : Electrolytic
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
