LG 42PC1RV-ZJ Service Manual

- 36 -
LOCA. NO PART NO DESCRIPTION
C908
C912
C915
C916
C917
C919
C921
C922
C926
C927
C928
C929
C930
C931
C932
C933
C934
C935
C936
C937
C938
C939
C941
C942
C943
C945
C946
C946
C947
C947
C948
C948
C949
C950
C951
C953
C955
C957
C958
C959
C960
C961
C962
C963
C964
C965
C967
C968
C969
C970
C972
C973
0CK474CH94A
0CE476WF6DC
0CK474CH94A
0CK104CK56A
0CE477WF6DC
0CK104CK56A
0CK103CK56A
0CE476WF6DC
0CK104CK56A
0CK104CK56A
0CK103CK56A
0CK103CK56A
0CK104CK56A
0CE476WF6DC
0CE476WF6DC
0CE477WF6DC
0CK104CK56A
0CE477WF6DC
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CE477WF6DC
0CK103CK56A
0CK103CK56A
0CK103CK56A
0CK104CK56A
0CE107WF6DC
0CE476WF6DC
0CE107WF6DC
0CE476WF6DC
0CE107WF6DC
0CE476WF6DC
0CK103CK56A
0CK104CK56A
0CE477WF6DC
0CE477WF6DC
0CE107WF6DC
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK104CK56A
0CK103CK56A
0CK103CK56A
0CK103CK56A
0CK103CK56A
0CK103CK56A
0CK103CK56A
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
47UF MVK 16V 20% R/TP(SMD) SMD
0.47UF 1608 25V 80%,-20% R/TP F(Y5V)
0.1UF 1608 50V 10% R/TP X7R
470UF MVK 16V 20% SMD R/TP(SMD)
0.1UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
47UF MVK 16V 20% R/TP(SMD) SMD
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
470UF MVK 16V 20% SMD R/TP(SMD)
0.1UF 1608 50V 10% R/TP X7R
470UF MVK 16V 20% SMD R/TP(SMD)
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
470UF MVK 16V 20% SMD R/TP(SMD)
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
100UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
100UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
100UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
0.01UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
470UF MVK 16V 20% SMD R/TP(SMD)
470UF MVK 16V 20% SMD R/TP(SMD)
100UF MVK 16V 20% R/TP(SMD) SMD
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.1UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
LOCA. NO PART NO DESCRIPTION
C974
C975
C976
C978
C979
C980
C981
C982
C983
C984
C985
C986
C988
C989
L1004
L801
L802
L808
L809
L910
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
JK303
JK304
R525
D1004
D750
LD101
SW101
SW102
SW103
SW104
SW105
SW106
0CK103CK56A
0CK103CK56A
0CK103CK56A
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE476WF6DC
0CE106WH6DC
0CK103CK56A
6140VB0004B
6140VR0008A
6140VR0008A
6140VR0008A
6140VR0008A
6140VB0004B
6631900012C
6631900027E
6631900048C
6631900050C
6631900097G
6631900098G
6631900107A
6631900108B
6631T39004D
6631V39013N
6630G70016A
6630G70017A
0RD0331H609
0DL233309AC
0DL233309AC
0DLAU0410AA
140-313B
140-313B
140-313B
140-313B
140-313B
140-313B
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
0.01UF 1608 50V 10% R/TP X7R
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
47UF MVK 16V 20% R/TP(SMD) SMD
10UF MVK 25V 20% R/TP(SMD) SMD
0.01UF 1608 50V 10% R/TP X7R
26UH 1UEWPHY 22.5TURN YL-9N 0.4
SLF12575T-330M4R7 33UH SMD COIL
SLF12575T-330M4R7 33UH SMD COIL
SLF12575T-330M4R7 33UH SMD COIL
SLF12575T-330M4R7 33UH SMD COIL
26UH 1UEWPHY 22.5TURN YL-9N 0.4
10P 2.5MM 200MM H-H UL1007AWG24
13P 2.5MM 300MM H-H UL1007AWG24
4P 2.0MM 250MM H-H UL1061AWG26
10P 2.0MM 1200MM H-H UL1185AWG26
3P 2.5MM 950/700MM H-T UL1007AWG24
4P 2.5MM 1050/700MM H-T UL1007AWG24
4P 1.25MM 400MM H-H UL1061AWG28
6P 2.0MM 700MM H-H UL1185AWG26
9P-9P H-H 220MM UL1007AWG18 TWI
8P 3.96MM 900MM H-H UL1617AWG22
A03-7071-094 SPG 15P 2.29MM RGB
A02-0915-101 SPG 9P 2.54MM RS232
3.3 OHM 1/2 W 5.00% TA52
SAM2333 TP KWANG GREEN/RED
SAM2333 TP KWANG GREEN/RED
AUK SAW5670 BULK AMBER/WHITE LAMP TYPE
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
TACT, 2LEAD 160G(TA) LG C&D 5V 0.001A
For Capacitor & Resistors,
the charactors at 2nd and 3rd
digit in the P/No. means as
follows;
CC, CX, CK, CN : Ceramic
CQ : Polyestor
CE : Electrolytic
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
COIL
CONNECTOR
RESISTOR
LED
SWITCH
