LG 42PQ3000 User Manual

15
EXTERNAL EQUIPMENT SETUP
HDMI IN
HDMI/DVI IN
2
1
AV IN 3
L/MONO
R
AUDIO
VIDEO
S-VIDEO HDMI IN 3
Connecting the HDMI cable
Connect the HDMI output of the DVD to the
HHDDMMII//DDVVII IINN 11
,
HHDDMMII IINN,, HHDDMMII IINN 22
or
HHDDMMII
IINN 33
jack on the TV.
Select
HHDDMMII11
,
HHDDMMII22
or
HHDDMMII33
input source using
the
IINNPPUUTT
button on the remote control.
Refer to the DVD player's manual for operating
instructions.
2
3
1
1
GG
The TV can receive video and audio signals simultaneously
when using a HDMI cable.
GG
If the DVD does not support Auto HDMI, you must set the
output resolution appropriately.
GG
Check that your HDMI cable is version 1.3 or higher.
If the HDMI cables don’t support HDMI version 1.3, flicker-
ing or no screen display can result. Please use the latest
cables that support at least HDMI version 1.3.
NOTE
!
Connecting with a S-Video cable
(Except for 42/50PQ10
**,
42/50PQ11
**
)
AV IN 3V IN 3
L/MONOMONO
R
AUDIOAUDIO
VIDEOVIDEO
S-VIDEOS-VIDEO HDMI HDMI IN IN 3
L R
S-VIDEOVIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Connect the S-VIDEO output of the DVD to the
SS --
VVIIDDEEOO
input on the TV.
Connect the audio outputs of the DVD to the
AAUUDDIIOO
input jacks on the TV.
Turn on the DVD player, insert a DVD.
Select
AAVV33
input source using the
IINNPPUUTT
button on
the remote control.
Refer to the DVD player's manual for operating instruc-
tions.
2
3
4
5
1
1
2
