Connect the
AAUUDDIIOO
/
VVIIDDEEOO
jacks between TV and
external equipment. Match the jack colours
.
(
Video =
yellow, Audio Left = white, and Audio Right = red
)
Select AV 3 input source using the
IINNPPUUTT
button on
the remote control.
Operate the corresponding external equipment.
Refer to external equipment operating guide.
2
3
1
1
Camcorder
Video Game Set
OTHER A/V SOURCE SETUP
(Except for 42/50PQ10
**,
42/50PQ11
**
)
Connect the USB device to the
UUSSBB IINN
jacks on the
side of TV.
After connecting the
UUSSBB IINN
jacks, you use the
UUSSBB
function. (
GG
pp..5533
)
2
1
USB SETUP
(Except for 42/50PQ10
**,
42/50PQ11
**
)
To Next Page
