7.3. RF Input(3D supported mode manually)
No. Resolution Proposed 3D input proposed mode
1 HD
1080I
720P
2D to 3D
Side by Side(Half)
Top & Bottom
2 SD
576P
576I
3 SD (ATV : CVBS / SCART) -
7.4. RF Input (3D supported mode automatically)
No. Signal 3D input proposed mode
1 Frame Compatible Side by Side(Half), Top & Bottom
7.2. HDMI Input(1.3)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 720*480 31.5 60 27.03 SDTV 480P
2D to 3D, Side by Side(Half), Top & Bot-
tom, Checker Board, Frame Sequential,
Row Interleaving, Column Interleaving
2 720*576 31.25 50 27 SDTV 576P
3 1280*720 45.00 60.00 74.25 HDTV 720P
4 1280*720 37.500 50 74.25 HDTV 720P
5 1920*1080 33.75 60.00 74.25 HDTV 1080I
2D to 3D, Side by Side(Half), Top & Bot-
tom
6 1920*1080 28.125 50.00 74.25 HDTV 1080I
7 1920*1080 27.00 24.00 74.25 HDTV 1080P
2D to 3D, Side by Side(Half), Top & Bot-
tom, Checker Board, Row Interleaving,
Column Interleaving
8 1920*1080 28.12 25 74.25 HDTV 1080P
9 1920*1080 33.75 30.00 74.25 HDTV 1080P
10 1920*1080 67.50 60.00 148.5 HDTV 1080P
2D to 3D, Side by Side(Half), Top &
Bottom, Checker Board, Single Frame
Sequential, Row Interleaving, Column
Interleaving
11 1920*1080 56.250 50 148.5 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode
1 Under 704x480 - - - 2D to 3D
2
Over 704x480
Under 1080P
interlaced
- - - 2D to 3D, Side by Side(Half), Top & Bottom
3
Over 704x480
Under 1080P
progressive
- 50 / 60 -
2D to 3D, Side by Side(Half), Top & Bottom, Checker Board,
Row Interleaving, Column Interleaving, Frame Sequential
4
Over 704x480
Under 7080P
progressive
- others -
2D to 3D, Side by Side(Half), Top & Bottom, Checker Board,
Row Interleaving, Column Interleaving
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode
1 Under 320x240 - - - 2D to 3D
2 Over 320x240 - - - 2D to 3D, Side by Side(Half), Top & Bottom
7.5. USB Input (3D supported mode manually)
7.6. USB (Photo) Input (3D supported mode manually)
