►y During USB operations such as Dvix or EMF, all commands except Power (k a) and Key (m c) are not executed and
treated as NG.
►y Some commands are not supported depending on the model.
►y The ‘f f’ command which shows the status of a certain command does not display the OSD as the result in order to be
compatible with SuperSign program.
COMMAND
DATA
(Hexadecimal)
1 2
35 Software version f z FF
36 White balance red gain j m 00 to FE
37 White balance green gain j n 00 to FE
38 White balance blue gain j o 00 to FE
39 Backlight m g 00 to 64
40 Screen off k d 00 to 01
41 Tile Mode d d See [Tile Mode]
42 Tile Mode Check d z FF
43 Tile ID d i Refer to ‘Tile ID'.
44 Tile H Position d e 00 to 32
45 Tile V Position d f 00 to 32
46 Tile H Size d g 00 to 32
47
Tile V Size
d h
00 to 32
48 Natural Mode (In Tile mode) d j 00 to 01
NOTE
