31
ENGLISH
LCD screen Pixel pitch 0.744 mm (H) x 0.744 mm (V)
Power Rated power AC 100-240 V~ 50/60 Hz 1.4 A
Power consumption On Mode: 120 W (Typ.)
Sleep Mode (RGB, DVI-D, HDMI): ≤ 1.0 W
Sleep Mode(DISPLAYPORT): ≤ 0.5 W
Off Mode: ≤ 0.5 W
Dimensions (Width
x Height x Depth) /
Weight
Head 1456.9 mm x 838 mm x 41.1 mm / 27.7 kg
(57.3 inches x 32.9 inches x 1.6 inches / 61.0 lbs)
Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 32.9 kg
(57.3 inches x 35.3 inches x 11.5 inches / 72.5 lbs)
Head + Speaker 1456.9 mm x 838 mm x 70.4 mm / 28.2 kg
(57.3 inches x 32.9 inches x 2.7 inches / 62.1 lbs)
Head + Speaker + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.4 kg
(57.3 inches x 35.3 inches x 11.5 inches / 73.6 lbs)
LCD screen Pixel pitch 0.744 mm (H) x 0.744 mm (V)
Power Rated power AC 100-240 V~ 50/60 Hz 1.4 A
Power consumption On Mode: 120 W (Typ.)
Sleep Mode (RGB, DVI-D, HDMI): ≤ 1.0 W
Sleep Mode(DISPLAYPORT): ≤ 0.5 W
Off Mode: ≤ 0.5 W
Dimensions (Width
x Height x Depth) /
Weight
Head 1456.9 mm x 838 mm x 56.5 mm / 27.9 kg
(57.3 inches x 32.9 inches x 2.2 inches / 61.5 lbs)
Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.1 kg
(57.3 inches x 35.3 inches x 11.5 inches / 72.9 lbs)
65SM5B
65SM5KB
Wireless module(LGSBW41) Specifications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth
Frequency range (MHz)
2400 to 2483.5
5150 to 5250
5725 to 5850
Frequency range (MHz) 2400 to 2483.5
Output power (Max.)
802.11a: 11.5 dBm
802.11b: 11 dBm
802.11g: 10.5 dBm
802.11n - 2.4 GHz: 11 dBm
802.11n - 5 GHz: 12.5 dBm
Output power (Max.) 10 dBm or Lower
• As band channels can vary per country, the user cannot change or adjust the operating frequency. This
product is configured for the regional frequency table.
• For consideration of the user, this device should be installed and operated with a minimum distance of
20 cm (7.8 inches )between the device and the body.
• Contains FCC ID: BEJLGSBW41 / Contains IC: 2703H-LGSBW41
