LG 43SM5KB User Manual

ENGLISH_index
45
01. [Power] (Command: k a)
Controls the power on/off of the set.
Transmission
(k)(a)( )(Set ID)( )(Data)(Cr)
Data 00: Off
01: On
02: Restart
Acknowledgement
(a)( )(Set ID)( )(OK/NG)(Data)(x)
* The acknowledgement signal is returned properly only when the
monitor is fully powered on.
* There may be a delay between the transmission and acknowledgement
signals.
02. [Select Input] (Command: x b)
Selects an input signal.
Transmission
(x)(b)( )(Set ID)( )(Data)(Cr)
Data 20: AV
40: COMPONENT
60: RGB
70: DVI-D (PC)
80: DVI-D (DTV)
90: HDMI1 (DTV)
A0: HDMI1 (PC)
91: HDMI2/OPS (DTV)
A1: HDMI2/OPS (PC)
92: OPS/HDMI3/DVI-D (DTV)
A2: OPS/HDMI3/DVI-D (PC)
95: OPS/DVI-D (DTV)
A5: OPS/DVI-D (PC)
96: HDMI3/DVI-D (DTV)
A6: HDMI3/DVI-D (PC)
98: OPS (DTV)
A8: OPS (PC)
C0: DISPLAYPORT (DTV)
D0: DISPLAYPORT (PC)
E0: SuperSign webOS Player
E1: Others
E2: Multi Screen
Acknowledgement
(b)( )(Set ID)( )(OK/NG)(Data)(x)
* Some input signals may not be supported depending on the model.
* Returns to NG if the webOS Player is not distributed from SuperSign W
or SuperSign Premium.
03. [Aspect Ratio] (Command: k c)
Adjusts the aspect ratio.
Transmission
(k)(c)( )(Set ID)( )(Data)(Cr)
Data 01: 4:3
02: 16:9
04: Zoom
06: Set by Program
09: Just Scan (720p or higher)
10~1F: Cinema Zoom 1 to 16
21: 58:9
30: Vertical Zoom
31: All-Direction Zoom
* Available data types differ depending on the input signal. For more
information, see the aspect ratio section of the owner’s manual.
* The aspect ratio may differ depending on the model’s input
configuration.
Acknowledgement
(c)( )(Set ID)( )(OK/NG)(Data)(x)
04. [Energy Saving] (Command: j q)
Sets the Energy Saving.
Transmission
(j)(q)( )(Set ID)( )(Data)(Cr)
Data 00: Off
01: Minimum
02: Medium
03: Maximum
04: Automatic
05: Screen off
Acknowledgement
(q)( )(Set ID)( )(OK/NG)(Data)(x)
* This may not be supported depending on the model.
