LG 43SM5KD Service Manual

- 6 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
SPECIFICATION
No. Item Specication Remarks
1 Supported Sync. Type Separate Sync, Digital
2 Operating Frequency
Analog
Horizontal 30 ~ 83 kHz
Vertical 56 ~ 75 Hz
Digital
Horizontal 30 ~ 83 kHz
Vertical
56 ~ 60 Hz (DVI-D,OPS)
30Hz,56 ~ 60Hz (HDMI1/2,DP)
3 Resolution
Analog
Max
1920×1080 @ 60Hz(RGB/DVI/OPS)
3840x2160@30Hz(HDMI1/2,DP)
Recommend 1920×1080 @ 60Hz
Digital
Max
1920×1080 @ 60Hz(RGB/DVI/OPS)
3840x2160@30Hz(HDMI1/2,DP)
Recommend 1920×1080 @ 60Hz
3.1. RGB, DVI-D, HDMI, Display Port (PC) Specication
1. Application range
This specication is applied to the LW79A chassis.
2. Test Specication
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F),
CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specication and performance of each parts are followed
each drawing and specication by part number in accord-
ance with BOM.
5) The receiver must be operated for about 20 minutes prior to
the adjustment.
3. General Specication

LG 43SM5KD Specifications

General

Brand	LG
Model	43SM5KD
Category	Digital Signage
Language	English
