No. Item Content Remark
1 Input HDMI 2 3840x2160@30Hz, HDMI1.4b HDCP2.2
Supporting color format (8 Bits)
- RGB444
- YCbCr444, YCbCr422
DP 1 3840x2160@30Hz, DP1.2a HDCP1.3
Supporting color format (8 Bits)
- RGB444
- YCbCr444
DVI 1 2K@60Hz,DVI-D Supporting color format (8 Bits)
- RGB444
RGB 1 Aanlog DSUB 15P
Supporting color format (8 Bits)
- RGB444
OPS 1 2K@60Hz Supporting color format (8 Bits)
- RGB444
USB 1 EMF, DVIX HD, For SVC(Download) USB3.0, Device: Memory stick, Mouse
Audio In 1 PC/DVI Audio In(L/R), Stereo 3P, 3.5mm Phone Jack
2 Output DP 1 SST Support HDMI1.4
- DP Daisy Chain : Not supported HDCP
Speaker Out 2 BTL(L+/-, R+/-), 6 ohm, Max. 10W 3P, 3.5mm Phone Jack
Audio Out 1 SE, Stereo L/R, 0.5Vrms 3P, 3.5mm Phone Jack
3 External RS232C IN/
OUT
1/1 UART Comm. w/ IR Daisy Chain 4P, 3.5mm Phone Jack
IR/Bright-
ness Sensor
1 External box type 5P, 3.5mm Phone Jack
LAN 1 RJ45, 10/100Base-T SuperSign Premium / SuperSign Link
4 Special
Feature
Temp. Sen-
sor
1 Built-in
Pixel Sensor 1 Optional
Wi-Fi 1 802.11n Built-in
Media
Player Com-
patibility
OPS Ready
External Media player Attatchable
Logo De-
tachable
Yes
3G/4G USB
Dongle
Download : 1Mbps, Upload : 0.5Mbps Over Indonesia Only (Continent Index : 82)
Support Dongles : Sierra - Aircard 320U, Hua-
wei - E3372/E1550
Support SIM : Telcomsel / Indosat / XL
5 Remote control Wireless Remote Control LG Code
6 Local Key INPUT, MENU, ˄, ˅, <, >, AUTO/SET, Φ/I 8 keys
7 Set Installation Wall Mount / Desk top Wall Mount Desk top
32/43: LSW230B
200*200
49/55/65: LSW350B
400*400
32/43:ST-432T
43/49/55:ST-432T
65:ST-652T
8 PIP / PBP Mode 2
9 SSC (Split Screen) Mode X
3.2. General Specication

LG 43SM5KD Specifications

General

Brand	LG
Model	43SM5KD
Category	Digital Signage
Language	English
