Page #11 background imageLoading...
Page #11 background image
- 11 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
(2) HDMI Input (3D Supported mode manually)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) VIC 3D input proposed mode Proposed
1 640*480
31.469 / 31.5 59.94/ 60 25.125/25.2 1
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
31.469 / 31.5 59.94/ 60 50.35/50.4 1 Side-by-side(Full) (SDTV 480P)
62.938/63 59.94/ 60 50.35/50.4 1
Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
2 720*480
31.469 / 31.5 59.94 / 60 27.00/27.03 2,3
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
31.469 / 31.5 59.94 / 60 54/54.06 2,3 Side-by-side(Full) (SDTV 480P)
62.938/63 59.94 / 60 54/54.06 2,3
Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
3 720*576
31.25 50 27 17,18
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576P)
Secondary(SDTV 576P)
31.25 50 54 17,18 Side-by-side(Full) (SDTV 576P)
62.5 50 54 17,18
Frame packing
Line alternative
Secondary(SDTV 576P)
(SDTV 576P)
15.625 50 27 21
Frame packing
Field alternative
Side-by-side(Full)
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576I)
(SDTV 576I
(SDTV 576I
Secondary(SDTV 576I)
Secondary(SDTV 576I)
4 1280*720
37.50 50 74.25 19
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
37.50 50 148.5 19 Side-by-side(Full) (HDTV 720P)
44.96 / 45 59.94 / 60 74.17/74.25 4
Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
44.96 / 45 59.94 / 60 148.35/148.5 4 Side-by-side(Full) (HDTV 720P)
75.00 50.00 148.50 19
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
89.91/90 59.94 / 60 148.35/148.5 4
Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
5 1920*1080
28.12 50.00 74.25 20
Frame packing
Line alternative
Secondary(HDTV 1080I)
Primary(HDTV 1080I)
28.12 50.00 148.50 20 Side-by-side(Full) (HDTV 1080I)
33.72 / 33.75 59.94 / 60.00 74.17/74.25 5
Top-and-Bottom
Side-by-side(half)
Secondary(HDTV 1080I)
Primary(HDTV 1080I)
33.72 / 33.75 59.94 / 60.00 148.35/148.50 5 Side-by-side(Full) (HDTV 1080I)
56.25 50.00 148.50 20
Frame packing
Field alternative
Primary(HDTV 1080I)
(HDTV 1080I)
67.43/67.50 59.94 / 60.00 148.35/148.50 5
Frame packing
Field alternative
Primary(HDTV 1080I)
(HDTV 1080I)
26.97 / 27.00 23.97 / 24.00 74.17 / 74.25 32
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Primary(HDTV 1080P)
26.97 / 27.00 23.97 / 24.00 148.35 / 148.50 32 Side-by-side(Full) (HDTV 1080P)
28.12 25.00 74.25 33
Top-and-Bottom
Side-by-side(half)
Secondary(HDTV 1080P)
Secondary(HDTV 1080P)
28.12 25.00 148.50 33 Side-by-side(Full) (HDTV 1080P)
33.71 / 33.75 29.97 / 30.00 74.18/74.25 34 Side-by-side(Full) (HDTV 1080P)
33.71 / 33.75 29.97 / 30.00 148.35/148.50 34
Frame packing
Line alternative
Primary(HDTV 1080P)
(HDTV 1080P)
43.94/54.00 23.97 / 24.00 148.35/148.50 32
Frame packing
Line alternative
Secondary(HDTV 1080P)
(HDTV 1080P)
56.25 25.00 148.50 33
Frame packing
Line alternative
Primary(HDTV 1080P)
(HDTV 1080P)
67.43 / 67.5 29.97 / 30.00 148.35/148.50 34
Frame packing
Line alternative
Primary(HDTV 1080P)
(HDTV 1080P)
56.25 50.00 148.50 31
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Secondary(HDTV 1080P)
67.43 / 67.50 59.94 / 60.00 148.35/148.50 16
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Secondary(HDTV 1080P)
