LG 43UF69 Series Service Manual

- 12 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
(3) DTV(3D) (3D supported mode automatically)
(4) DTV/ATV(CVBS/SCART) Input(3D) (3D supported mode manually)
No. Signal H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 Frame compatible 48.36 60 65 HDTV 768P Side by Side(half), Top & Bottom
No. Signal H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 HD/SD 48.36 60 65 HDTV 768P
2D to 3D, Side by Side(half)
Top & Bottom
2 SD Side by Side(half), Top & Bottom
(5) Component Input (3D) (3D Supported mode manually)
(6) HDMI-PC Input (3D) (3D supported mode manually)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1280*720 37.50 50.00 74.25 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom
2 1280*720 45.00 60.00 74.25 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom
3 1280*720 44.96 59.94 74.18 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom
4 1920*1080 33.75 60.00 74.25 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom
5 1920*1080 33.72 59.94 74.18 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom
6 1920*1080 28.12 50.00 74.25 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom
7 1920*1080 67.50 60.00 148.50 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
8 1920*1080 67.43 59.94 148.35 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
9 1920*1080 27.00 24.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
10 1920*1080 28.12 25.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
11 1920*1080 56.25 50.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
12 1920*1080 26.97 23.97 74.18 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
13 1920*1080 33.75 30.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
14 1920*1080 33.71 29.97 74.18 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1024*768 48.36 60.00 65.00 HDTV 768P
2D to 3D, Side by Side(half), Top & Bottom
2 1360*768 47.71 60.00 HDTV 768P
3 1920*1080 67.50 60.00 148.50 HDTV 1080P
2D to 3D, Side by Side(half), Top & Bottom,
Checker Board, Frame Sequential, Row
Interleaving, Column Interleaving
4
3840*2160
(Ultea HD
model only)
54.00 24.00 296.70
HDTV 2160P
2D to 3D, Top & Bottom(half)
Side by Side(half)
56.25 25.00 297.00
67.50 30.00 296.70
5
4096*2160
(Ultea HD
model only)
54 24.00 297.00 HDTV 2160P
6 Others - - -
640*350
720*400
640*480
800*600
1152*864
2D to 3D, Side by Side(half), Top & Bottom
