- 13 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
(7) HDMI-DTV (3D supported mode manually)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 720*480 31.50 60.00 27.03 SDTV 480P
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Frame Sequential, Row
Interleaving, Column Interleaving
2
720*576
31.25 50.00 27.00 SDTV 576P
3 37.50 50.00 74.25 HDTV 720P
4 1920*1080
33.75 60.00 74.25 HDTV 1080I
2D to 3D, Side by Side(Half), Top & Bottom
28.12 50.00 74.25 HDTV 1080I
5 1920*1080
27.00 24.00 74.25 HDTV 1080P
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Row Interleaving, Column
Interleaving
28.12 25.00 74.25 HDTV 1080P
33.75 30.00 74.25 HDTV 1080P
67.50 60.00 148.50 HDTV 1080P
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Single Frame Sequential,
Row Interleaving, Column Interleaving
56.25 50.00 148.50 HDTV 1080P
6
3840*2160
4096*2160
(Ultra HD
model only)
53.95 23.97 297.00
HDTV 2160P
2D to 3D,
Top & Bottom(half), Side by Side(half)
54.00 24.00 296.70
56.25 25.00 297.00
61.43 29.97 297.00
67.50 30.00 296.70
112.50
50.00(HDMI1,
HDMI2 Only)
594.00
HDTV 2160P 2D to 3D, Side by Side(half), Top & Bottom
135.00
60.00(HDMI1,
HDMI2 Only)
594.00
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode
1 Under 704x480 - - - 2D to 3D
2
Over 704x480
Under 1080P
interlaced
- - - 2D to 3D, Side by Side(Half), Top & Bottom
3
Over 704x480
Under 1080P
progressive
- 50 / 60 -
2D to 3D, Side by Side(Half), Top & Bottom, Checker
Board, Row Interleaving, Column Interleaving, Frame
Sequential
- others -
2D to 3D, Side by Side(Half), Top & Bottom, Checker
Board, Row Interleaving, Column Interleaving
4 Over 2160P - 24/25/30/50/60 - 2D to 3D, Side by Side(Half), Top & Bottom
(8) USB - Movie (3D) (3D supported mode manually)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode
1 USB(photo) - - - 2D to 3D, Side by Side(Half), Top & Bottom
(9) USB, DLNA -Photo (3D) (3D supported mode manually)
