8
ENGLISH
Installation Location
We are not responsible for product damage caused by failure to follow the guide.
Indoor
Installing on a Wall
13 mm (0.5inches) (Slim Wall Mount, optional)
26 mm (1.0inches) (Normal Wall Mount, optional)
A
A
A : 13mm (0.5inches) or more
• The warranty will not cover any damage
caused by using the product in direct sunlight
on the front panel.
• Leave sufficient space around the product so
that the ventilation vents of the product are
not blocked.
Installing on a Recessed Wall
A
A
A : 13mm (0.5inches) or more
B : 50mm (1.9inches) or more
C : 70mm (2.7inches) or more
• The warranty will not cover any damage
caused by using the product in direct sunlight
on the front panel.
Outdoor
Outdoor Enclosed
