LG 47LB2RF - Page 25

- 25 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
30919E0042F Cover Assembly, 47LB1R-ZH(CKD) LP62H 47" C/A ASSY FOR SET
30919E0042D Cover Assembly, 47LB1R-ZH LP62H-H 47" C/A ASSY FOR SET
EAJ31412401
LCD,Module-TFT, LC470WU1-SLA1 FULLHD 47INCH 1920X1080 550CD COLOR 72% 16/9 800vs1 P7 Factory
3809900160C Cover Assembly, 47LB1R-CH LP62H 47" FOR SET
3043900027C Base Assembly, STAND 47LB1R-ZH(CKD) LP62H BLACK
3043900027A Base Assembly, 47LB1 . .
EBR32285201 PCB Assembly SUB, PAKING LP62H 47LB1R-CH SKD CONTROL KEY PACKING
EBR32285001 PCB Assembly SUB, PAKING LP62H 47LB1R-CH SKD INDEX PACKING
4810900041A Bracket, MOLD ABS SUPPORTER 47LB1D AB00EA ABS CABLE MANAGEMENT
AGU30990803 Plate Assembly, ASSY METAL MAIN FRAME(47LB1,CH,CKD)
AGU30990802 Plate Assembly, ASSY METAL MAIN FRAME(47LB1,CH)
EBR32284902 PCB Assembly, MAIN1 PAKING LP62H 47LB2RF-ZH SKD PACKING
6401900127B Speaker Assembly, 42LB1 SIDE LEFT(1350MM)
6401900127J Speaker Assembly, 47LB1R-CH SIDE RIGHT(1250MM)
6401900131B Speaker Assembly, 42LB1 WOOFER LEFT(970MM)
6401900131G Speaker Assembly, 47LB1R-CH WOOFER RIGHT(850MM)
EBR32285102 PCB Assembly SUB, PAKING LP62H 47LB2RF-ZH SKD SIDE PACKING
AGU30256704 Plate Assembly, SHIELD, analog shield assy for 47LB1R-ZH(CKD)
AGU30256702 Plate Assembly, SHIELD, analog shield assy for 47LB1R-ZH
33139L4003C Main Total Assembly, 47LB1R-ZH BRAND LP62H EU
6709900018B Power Supply Assembly, 4655E FREE H3/E2 LCD LCD YY LB LC 47INCH
4810900029A Bracket, MOLD ABS REAR AV 47LB1D SP02PC ABS (47)
010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170
180
