- 26 -

DATE: 2006. 09. 05.

*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION

C1005 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C1007 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16

C1012 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16

C1014 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C1016 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1019 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C1020 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1022 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C1023 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1

C1031 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50

C1048 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C1049 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1050 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1053 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1054 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1062 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1063 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C1064 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1065 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1067 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C1069 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1

C1070 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1072 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1084 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1085 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1086 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1087 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1088 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1089 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1092 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1101 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1

C1107 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1

C1113 0CE227WF6DC MVK8.0TP16VC220M 220uF 20%

C1129 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C1130 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1131 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1132 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C1135 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1137 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1146 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16

C1147 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C1149 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1151 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1152 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%

C1157 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1158 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16

C118 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C119 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C1201 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1207 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1222 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C1226 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

DATE: 2006. 09. 05.

*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION

C124 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C1244 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C125 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C126 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C127 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C132 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C135 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C136 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C1402 0CH8106J691 MVK5.0TP35VC10M 10uF 20% 35

C1403 0CH8106J691 MVK5.0TP35VC10M 10uF 20% 35

C142 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C1460 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C1468 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C148 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C149 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C174 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C175 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C1814 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C1826 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C210 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C211 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C213 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C215 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C224 0CE477SF6DC VMV477M016S0ANG030 470uF 20

C237 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C238 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%

C314 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C316 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C317 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C318 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C349 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C351 0CE105SK6DC VMV105M050S0ANB010 1uF 20%

C354 0CE105SK6DC VMV105M050S0ANB010 1uF 20%

C401 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C405 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C409 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C412 0CE335SK6DC VMV335M050S0ANB010 3.3uF 20

C432 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C446 0CE335SK6DC VMV335M050S0ANB010 3.3uF 20

C451 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C452 0CE106SH6DC VMV106M025S0ANB010 10uF 20%

C463 0CE475SK6DC VMV475M050S0ANB010 4.7uF 20

C464 0CE475SK6DC VMV475M050S0ANB010 4.7uF 20

C466 0CE475SK6DC VMV475M050S0ANB010 4.7uF 20

C467 0CE475SK6DC VMV475M050S0ANB010 4.7uF 20

C512 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20%

C611 0CZZTAT006D RV2-16V101MSU-R 100uF 20% 1

C834 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C835 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C836 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C837 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C838 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C839 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

C840 0CE226SF6DC VMV226M016S0ANB010 22uF 20%

REPLACEMENT PARTS LIST

MAIN BOARD

CAPACITOR

For Capacitor & Resistors, the

charactors at 2nd and 3rd digit in the

P/No. means as follows;

CC, CX, CK, CN, CH : Ceramic

CQ : Polyestor

CE : Electrolytic

CF : Fixed Film

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RH : CHIP, Metal Glazed(Chip)

RR : Drawing
