DATE: 2006. 09. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R458 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R460 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R461 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R462 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R481 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1
R482 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1
R494 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R516 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R517 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R518 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R520 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R521 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R524 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R525 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R526 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R527 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R600 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R601 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R602 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R603 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R607 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R608 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R609 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R619 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1
R621 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R800 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R807 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R808 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R810 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R814 0RJ2701D677 MCR03EZPJ272 2.7KOHM 5% 1/1
R815 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1
R818 0RJ2701D677 MCR03EZPJ272 2.7KOHM 5% 1/1
R819 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R821 0RJ3301D677 MCR03EZPJ332 3.3KOHM 5% 1/1
R823 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R825 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R827 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R829 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R830 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R833 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R835 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R836 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R837 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R839 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R840 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R841 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R844 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R845 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R846 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R847 0RH0202D622 MCR10EZHJ200 20OHM 5% 1/8W
R849 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R852 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R853 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R861 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R862 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R863 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R864 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R867 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R868 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R870 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R871 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R872 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
DATE: 2006. 09. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R873 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R874 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R878 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R879 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R880 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R881 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R882 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R883 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R884 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R885 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R893 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R894 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R905 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R906 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R907 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R910 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R911 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R912 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R917 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R918 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
X400 156-A02M HC-49/U 18.432MHZ 30PPM 18.
X1200 6202TST001H SX-1 27MHZ 30PPM 27MHZ 30PP
X800 6212AB2015G HC-49/SM 19.6608MHZ 30PPM 1
D1003 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2.
D1103 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2.
X300 166-E02F CSBLA500KECZF09-B0 500KHZ 2
SW800 6600VR1004A SKHMPWE010 1C1P 12VDC 0.05A
SW900 6600VR1004A SKHMPWE010 1C1P 12VDC 0.05A
TU200 6700MF0017B TAFV-W302P PAL - - - - HORI
TU201 6700MF0017A TAUV-W301P PAL - - - - HORI
C101 0CH5101K416 C2012C0G1H101JT 100pF 5% 50
C102 0CH5101K416 C2012C0G1H101JT 100pF 5% 50
R101 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R102 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R103 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R105 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R106 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
C102 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%
C103 0CH5330K416 C2012C0G1H330JT 33pF 5% 50V
C104 0CH2103K516 0805B103K500CT 10nF 10% 50V
C105 0CH3104K566 0805B104K500CT 100nF 10% 50
C106 0CE106SH6DC VMV106M025S0ANB010 10uF 20%
C108 0CE106SH6DC VMV106M025S0ANB010 10uF 20%
C109 0CE106SH6DC VMV106M025S0ANB010 10uF 20%
C111 0CE106SH6DC VMV106M025S0ANB010 10uF 20%
C115 0CE227SF6DC MVG6.3TP16VC220M 220uF 20%
IC102 0IMI623200B M62320FP 4.5TO5.5V 0.05mA 4
IC103 0IMCRFA015A KA7805R 7TO20V 5V 150W DPAK
L105 6210TCE001G HH-1M3216-501JT 500OHM 3.2X
Q102 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q103 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q104 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
- 37 -
INDEX BOARD
OTHERs
SIDE A/V BOARD
