LG 47LB2RF - Page 38

DATE: 2006. 09. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q105 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q106 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q107 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q108 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
R105 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W
R106 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R107 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R108 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R109 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R110 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R111 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R112 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R115 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W
R116 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R117 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R118 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R119 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R120 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R121 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R122 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R123 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R124 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R125 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R126 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R127 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R128 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R140 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
C101 0CH3104K566 0805B104K500CT 100nF 10% 50
C107 0CH3104K566 0805B104K500CT 100nF 10% 50
C110 0CH3104K566 0805B104K500CT 100nF 10% 50
C112 0CH3104K566 0805B104K500CT 100nF 10% 50
L101 0LC2232101A FI-D3216-223KJT 22UH 10% -
L103 6210TCE001G HH-1M3216-501JT 500OHM 3.2X
L104 6210TCE001G HH-1M3216-501JT 500OHM 3.2X
Q101 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q109 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
R101 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R102 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R103 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R129 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R136 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R141 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R142 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W
R143 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
D101 0DLAU0410AA SAW5670 ROUND 5mM AMBER/WHI
D102 6301900003A WHITE 6HOLE WHITE 3V 20MA 8
IC101 6712000011B KSM-2013TE2A 4.5TO5.5V 1.3M
SW101 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW102 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW103 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW104 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW105 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW106 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW107 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW108 140-313A THVV501BBC 1C1P 12VDC 0.05A
R101 0RH1302D622 MCR10EZHJ133 13KOHM 5% 1/8W
R102 0RH1302D622 MCR10EZHJ133 13KOHM 5% 1/8W
R103 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
DATE: 2006. 09. 05.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R104 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R105 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8
R106 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8
R107 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R108 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
ZD101 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80
ZD102 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80
- 38 -
CONTROL BOARD
