- 11 -
9. General specifications
9-1. 47" LCD MODULE
No Item Specification Unit Remark
1 Active Screen Size 46.96 inches(1192.87mm) mm
2 Outline dimension 1096.0(H)x640.0(V)x481(D) mm
3 Pixel Pitch 0.5415x0.5415x RGB mm
4 Pixel Format 1920 horiz by 1080 vert. RGB Stripe arrangement
5 Color Depth 8-bit / 16.7M Color
6 Luminance, White 550 cd/m2
7 Power Consumption Total 230.56 Watt
8 Weight 20.0Kg
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H) Anti-glare treatment of the front polarizer
9-2. 42" LCD MODULE
No Item Specification Unit Remark
1 Active Screen Size 42.02 inches(1067.31mm) mm
2 Outline dimension 983.0(H)x576.0(V)x51.0(D) mm
3 Pixel Pitch 0.4845x0.4845x RGB mm
4 Pixel Format 1920 horiz by 1080 vert. RGB Stripe arrangement
5 Color Depth 8-bit / 16.7M Color
6 Luminance, White 550 cd/m2 (Center 1 point, Typ) kg
7 Power Consumption Total 167.3 Watt(Typ)
8 Weight 13Kg
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H), Anti-glare treatment of the front polarizer
9-3. 37" LCD MODULE
No Item Specification Unit Remark
1 Active Screen Size 37.02 inches(940.3mm) mm
2 Outline dimension 877.0(H)x516.8(V)x55.5(D) mm
3 Pixel Pitch 0.200 x 0.600 x RGB mm
4 Pixel Format 1366 horiz by 768 vert. RGB Stripe arrangement
5 Color Depth 8-bit / 16.7M Color, 10-bit / 1 G colors
6 Luminance, White 550 cd/m2 (Center 1 point, Typ) kg
7 Power Consumption Total TDB Watt
8 Weight 9.5Kg
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H), Anti-glare treatment of the front polarizer
