LG 47LB5DF - Exploded View Parts List

- 46 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
120 EAB33775101 Speaker,Full Range, EN1562C-6712 ND 10W 8OHM 82DB 100HZ 193.5 X 42 X 39.9 LUG KOREA TOPTONE
121 EAB33893101
Speaker,Tweeter, EN10D-6714 ND 10W 8OHM 82DB 0HZ 68 X 23 X 22.7 LUG KOREA TOPTONE
200 EAJ35565901 LCD,Module-TFT, LC470WU1-SLB2 FULLHD 47INCH 1920X1080 550CD COLOR 72% 16/9 800:1(basic) DCR(1600:1) A-TW Pol. 12000K P7 LG PHILIPS LCD
300 ABJ32083303 Cabinet Assembly, 47LB5 LA73A 47" XG569 CABINET ASS'Y FOR SKD
400 ACQ32083406 Cover Assembly, 47LB5 LA73A 47" HIPS 405AF BACK COVER ASS'Y FOR SKD
500 6500VR0003E
Sensor,Ambient Light, YGCA-T071C 12 HOUSING BK 26.4X20X26.4mm VOUT 5V(AT 80LUX) LG INNOTEK CO., LTD
510 EBR35909801 PCB Assembly,Sub, SUB T.T LA73A 47LB5DF-UC AUSLLHX SUB T.T LA73A 47LB5DF-UC IR total
520 EBR35015201 PCB Assembly,Sub, SUB T.T LA73A 47LB4DF-UA - Control key total
530 EBR35015401 PCB Assembly,Sub, SUB T.T LA73A 47LB4DF-UA - Side AV total
600 EAY32816901
SMPS,AC/DC, FSP327-6F01 90VTO264V 375W 50/60 CB, UL, IEC600,650 etc... LCD 47inch SPI PSU for New chassis(E3 etc...) SPI ELECTRONIC CO.,LTD
610 EBU35309101 Main Total Assembly, 47LB5DF-UA BRAND LA73A
800 MGJ32889304
Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR TOP(47LY3)_ NORMAL MODULE_ FOR C/SKD
801 MGJ32889604 Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR BOTTOM (47LY3)_GENERAL MODULE_ FOR C/SKD
802 MGJ32889802 Plate,Metal, PRESS SBHG1 1.6 METAL EGI METAL BAR, LEFT (47LY3) FOR C/SKD
803 MGJ32897004
Plate,Metal, PRESS SBHGI 1.6 METAL EGI BAR CENTER (47LY3),FAD30046142(PEMNUT) FOR C/SKD
804 MGJ32890003 Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR RIGHT (47LB4, PEM-NUT 'YES') FOR C/SKD
805 MGJ32897104 Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR SIDE TOP (47LB5DF-UC) EV3_FOR C/SKD
806 MGJ32897204
Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR SIDE BOTTOM (47LB5DF-UC) EVE3_FOR C/SKD
807 MGJ32897302 Plate,Metal, PRESS SBHG1 1.6 METAL EGI BAR SUPPORTER (47LY3) FOR C/SKD
810 MGJ32918107 Plate,Shield, PRESS SPTE 0.5 SHIELD SPTE COVER MAIN "01"C/SKD(EV3)
820 EBR36524801 PCB Assembly,Sub, SUB T.T LA71A 42LY3DR-NA AKRLLH AC-Inlet Ass'y Total
830 MAZ37752001 Bracket, MOLD HPS 51SF HANDLE 47LB4 LD73A HIPS 51SF 47LB4 CABLE MANAGEMENT(
840 MGJ37663503
Plate,Shield, PRESS SPTE 0.5 SHIELD SPTE 47LY3/LB4/LB5/LC7 POWER SHIELD FOR C/SKD
850 MAZ34946201 Bracket, MOLD HIPS 405AF STAND 47LC5 LA73A HIPS 405AF Guide
900 AAN33079802
Base Assembly, STAND 47LB5 LD75A STAND ASSY_NO_PRINT C/SKD (HIGH GLOSSY ROUND TYPE)
