Check SIF lines
C6025, C6026
Check MSP4450K (IC508) inputs
C5016, #67pin
1
2
3
4
5
6
Follow the procedure of
“COMMON SOUND OUT”
7
8
Check Tuner (TU600)
5V (3,5,9,17 pin), SIF(18 pin)
Check Antenna Cable
Check X260 (IC101) Intputs
R175(SCLK), R176(LRCLK), R177(DATA)
Check MSP4450K (IC508) Power
Check MSP4450K (IC508) outputs
R5039(SCLK), R5040(LRCLK), R5043(DATA)
