Check CS8416 (IC501) inputs
HDMI_SPDIF (C5005)
1
2
3
4
5
Follow the procedure of
“COMMON SOUND OUT”
6
Check MST3361 (IC402) output
HDMI_SPDIF (R409)
Check HDMI Cable
Check X260 (IC101) Inputs
SCLK(R175), LRCLK(R176), DATA(R177)
Check CS8416 (IC501) outputs
DATA(#26), SCLK(#27), LRCLK(#28)
To Next Page
