LG 47LB5DF - Page 61

- 61 -
R7087 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R712 0RJ0752C678 "Resistor,Chip" MCR01MZPJ750 75OHM 5% 1
R713 0RJ0752C678 "Resistor,Chip" MCR01MZPJ750 75OHM 5% 1
R714 0RJ0752C678 "Resistor,Chip" MCR01MZPJ750 75OHM 5% 1
R715 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R716 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R717 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R718 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R719 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R720 0RJ0752C678 "Resistor,Chip" MCR01MZPJ750 75OHM 5% 1
R721 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R721 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R723 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R723 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R724 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R724 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R726 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R726 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R728 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R729 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R729 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R730 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R733 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R733 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R736 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R737 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R738 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R739 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R740 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R741 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R744 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R745 0RJ4703C678 "Resistor,Chip" MCR01MZPJ474 470KOHM 5%
R748 0RJ0102C678 "Resistor,Chip" MCR01MZPJ100 10OHM 5% 1
R749 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R750 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R752 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5% 1
R771 0RJ2203D677 "Resistor,Chip" MCR03EZPJ224 220KOHM 5%
R772 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R773 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R774 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R775 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1/
R777 0RJ2002D677 "Resistor,Chip" MCR03EZPJ203. 20KOHM 5%
R778 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R779 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5% 1
R782 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R783 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R784 0RJ0511D677 "Resistor,Chip" MCR03EZPJ5R1 5.1OHM 5%
R785 0RJ0511D677 "Resistor,Chip" MCR03EZPJ5R1 5.1OHM 5%
R786 0RJ1502C478 "Resistor,Chip" MCR01MZPF153 15KOHM 1%
R787 0RJ1502C478 "Resistor,Chip" MCR01MZPF153 15KOHM 1%
R804 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
X100 EAW30352304 Crystal 9C55400023(16pf) 55.474
X300 6202TST001E Crystal SX-1 24MHZ 30PPM(20PF)
X400 6202VDT002B Crystal SX-1 14.31818MHZ 30PPM(
X500 6202VDT002H Crystal SX-1 18.432MHZ 30PPM(16
X601 6212AB2872A Crystal HC49SM 25MHZ 50PPM 20pF
X900 6212AB2872A Crystal HC49SM 25MHZ 50PPM 20pF
J101 6612J10033A "Jack,Complex" PMJ016-13 13P DIN/RCA 1
J600 6612J10024A "Jack,Complex" KCN-BT-0-0056 4P NT/RCA
J705 6612J00062H "Jack,Complex" PMJ029-01 14P DIN/RCA 1
J402 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P S
J403 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P S
J404 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P S
J1 EAG32151101 "Jack,Fiber Optic" "TOX177L(F,T) 3P TX 2.54"
J702 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIGH
J703 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIGH
J400 6612J10031A "Jack,RCA" PPJ209-02 14.0MM 1RX5C
J401 6612J10031A "Jack,RCA" PPJ209-02 14.0MM 1RX5C
J704 6612J10043A "Jack,RCA" PPJ200-07 15MM 1RX4C AN
LED1 0DLBE0138AA "LED,DIP" BL-BUBGE301 ROUND 3MM S
IC205 SAA30532516 "S/W,Firmware" 3.06 0DD3 NORTH AMERICA
IC309 SAA30643715 "S/W,Firmware" 3.02 B45B WORLD WIDE Su
SW101 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW102 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW103 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW104 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW105 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW106 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW107 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
SW108 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC 0
TU600 EBL34917003 "Tuner,Analog/Digital" VA1Y2UR2201 NTSC/ATSC 5
VR400 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR401 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR402 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR403 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR404 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR405 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR405 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR406 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR406 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR407 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR407 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR408 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR409 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR410 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
VR411 6102W5V016A Varistor AVRL161A1R1NT 10V 30% 1
J300 6630G00001C "Connector,DSUB" KCN-DS-1-0088 D-SUB 9P
J404 6630TGA004K "Connector,DSUB" KCN-DS-1-0089 D-SUB 15P
J405 6630TGA004K "Connector,DSUB" KCN-DS-1-0089 D-SUB 15P
P103 6630SK00604 "Connector,USB" UAR27-4K2300 A 1P 2.50M
P101 6602T20009C "Connector,Wafer" SMAW200-04P 4P 2.00MM 1
P101 6602T20009L "Connector,Wafer" SMAW200-12P 12P 2.00MM
P102 6602T20008N "Connector,Wafer" SMW200-14P 14P 2.00MM 1
P102 6602T20009C "Connector,Wafer" SMAW200-04P 4P 2.00MM 1
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
OTHERs
CONNECTOR
