LG 47LT360C - Block Diagram

- 20 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
RGB PC
HDMI(DVI) 1/2
TUNER (TDSS - G101D)
PC/DVI Audi In
RS- 232C
IF
TU_CVBS
SIF
S7LR
MAX3232
SERIAL FLASH MXIC (8M bit)
MX25L8006EM2I
LVDS
(60Hz/FHD/HD)
A. AMP
NTP7400
USB2.0
DP/DM
SPK L/R
X-
tal
24M
51P
I2S
RGB/H/V
RS232C
Rear
TMDS
DDR2 Add.
DDR2 Data
SPI
AV
Side
NAND Flash
(1Gbit)
NAND01GW3B2CN6E
PCM_A[0:7]
TMDS
HDMI3
CVBS, L/R
DDR3 256MB
Hynic
H5TQ1G63DFR
DDR3 256MB
Hynic
H5TQ1G63DFR
CONTROL IR & LED
LED_R/BUZZ
KEY1 KEY2
IR
LED_B/LG LOGO
M24M01 - HRMN6TP
1Mbit
HDCP EEPROM
CAT24WC08W -T
I2C
TI AMP
External SPK Out
L/R
30P
IRout -Path(Pin 4)
L/R
TMDS
+3.5Vst
COMPONENT
BLOCK DIAGRAM
